AOS Supernova 3220 1000KV Brushless Motor for TBS Mojito, 6S-8S, 32 x 20 mm Stator
AOS Supernova 3220 1000KV Brushless Motor for TBS Mojito, 6S-8S, 32 x 20 mm Stator
teamblacksheep
Regular price
$90.93 USD
Regular price
Sale price
$90.93 USD
Unit price
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Overview
The AOS Supernova 3220 1000KV brushless motor is specified for the TBS Mojito and is suitable for high-speed FPV wing applications. Its 1000KV rating is intended for steep-pitch 7-10 inch propellers on 6S-8S battery systems.
Key Features
- 3220 stator configuration with a 32 x 20 mm stator size
- 12N14P slot and pole arrangement
- 19 x 19 mm M3 mounting pattern
- 250 mm motor lead
- 5 mm propeller shaft diameter
- Throttle expo setup guidance for Betaflight: Throttle MID = 0 and Throttle EXPO = 0.20
Specifications
| Model | AOS Supernova 3220 |
| KV Rating | 1000KV |
| Stator Size | 32 x 20 mm |
| Slot Poles | 12N14P |
| Mounting Pattern | 19 x 19 mm, M3 |
| Weight | 170 g with wire |
| Lead Length | 250 mm |
| Prop Shaft Diameter | 5 mm |
| Input Voltage | 6S-8S |
| Recommended Propeller Size | 7-10 inch, steep pitch |
Applications
Designed for the TBS Mojito and high-speed FPV power cruiser wings using 6S-8S power systems. For product support, contact rcdrone.top.
