BrotherHobby LPD 2306.5 2000KV/2450KV/2650KV Brushless Motor for 5-6S FPV Freestyle Racing Drones

BrotherHobby LPD 2306.5 2000KV/2450KV/2650KV Brushless Motor for 5-6S FPV Freestyle Racing Drones

Brotherhobby

$52.11 USD
$52.11 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Color
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
View full details

Overview
The BrotherHobby LPD 2306.5 Brushless Motor is engineered for high-performance FPV freestyle and long-range racing drones. With powerful 2000KV, 2450KV, and 2650KV variants, this motor offers exceptional thrust, high efficiency, and reliable construction for both beginners and pro pilots. It's the perfect upgrade for 5-6 inch FPV builds, delivering unmatched control, smooth throttle response, and long-lasting durability.

Specifications

Parameter 2000KV 2450KV
Max Thrust 2048g 1899g
Input Voltage 6S (23.7V) 5S (19.9V)
Max Current 52.9A 52.7A
Max Power 1253.73W 1048.73W
Efficiency 1.63 g/W 1.81 g/W
Rotor Speed 31735 RPM 29233 RPM
Propeller Tested HQ 5.1x4.1x3 HQ 5.1x4.1x3
ESC Recommendation 55A 55A
Motor Temperature 156.3°C 121.5°C
Configuration 12N14P 12N14P
Stator Size 2306.5 2306.5
Mounting Holes M3 (16x16mm) M3 (16x16mm)
Shaft Diameter M5 M5
Weight Approx. 34g Approx. 34g

Key Features

  • Unibell Design: CNC 7075 aluminum for increased strength and crash resistance.

  • High Efficiency: Up to 2048g of thrust at just 1253W for 2000KV.

  • Precision Windings: High-temperature resistant copper wire with 260°C insulation.

  • N52H Curved Magnets: Ensures high torque output with smooth response.

  • Durable Bearings: Equipped with Japanese NMB 9x4x4mm bearings for smooth rotation and long life.

  • Advanced Cooling: Aerodynamic bell cap and stator design reduce motor heat buildup.

Application
Ideal for 5" to 6" FPV racing drones, freestyle quads, and fixed-wing builds that demand high torque, aggressive acceleration, and stable flight.

Package Includes

  • 1x BrotherHobby LPD 2306.5 Motor

  • 4x M3 Screws

  • 1x M5 Propeller Nut
