  • BrotherHobby Tornado T5 3115 Pro Motor 400/640/900/1050/1200KV FPV Drone Motor
  • BrotherHobby Tornado T5 3115 Pro Motor 400/640/900/1050/1200KV FPV Drone Motor
  • BrotherHobby Tornado T5 3115 Pro Motor 400/640/900/1050/1200KV FPV Drone Motor
1 4

BrotherHobby Tornado T5 3115 Pro Motor 400/640/900/1050/1200KV FPV Drone Motor

BrotherHobby Tornado T5 3115 Pro Motor 400/640/900/1050/1200KV FPV Drone Motor

Brotherhobby

$45.99 USD
$45.99 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

199 orders in last 90 days

KV
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details
Specifications
KV: 900KV/1050KV/1520KV
Base casing: Al 7075
Stator: 0.2mm Kawasaki silicon steel
Configuration: 12N14P
Prop Adapter Shaft Thread: M5
Shaft: Titanium Alloy hollow shaft
No.of Cells(Lipo): 5-8S
Bolt Pattern: M3 (19X19mm)
Bearings: Japanese NMB 11mm X 5mm X 5 mm
Rotor: N52H arc magnets
Weight: 110g with 25cm SR wires
Wire AWG: 18AWG 25cm length
Bell cap: Al 7075
TORNADO TS 3115 MOTOR TS 7@ ULTRALIGHT DUR
Specifications KV: 900KV/1050KV/1520KV Base cas
YH Zheng Auditor: Melo Lee Date: 2018/11/22 TestBrotherHobby Tornado T5 3YH Zheng Auditor: Melo Lee Date: 2018/10/31 Test

Test Report: Tornado T5 3115 Pro Motor (Date: October 31, 2018, Auditor: Melo Lee) Specifications: * Drawing Number: 49.5 * Stator Height: 37.5mm * Stator Dimension: 19mm x 16mm * M3 Specification: 12N14P * KV Configuration: 1050KV * Motor Dimensions (mm): Length - 250mm, Weight including cable - 110.23g * Magnet Type: Ns2H * Internal Resistance: 35.16mo * Idle Current: unknown

KV 1200KV Configuration 12NI4P Stator Dimension (mm) 31

Specifications: * KV: 1200KV * Configuration: 12N14P * Stator Dimension (mm): 31 x 31 * Stator Height (mm): 15 AWG, 18# * Length (mm): 250 * Motor Dimensions (mm): 37.5 x 49.5 * Weight including cable (g): 110.66 * Magnet Type: N52H * Internal Resistance (mΩ): 25.97 * Idle Current @1V (A): 2.66 * Number of Cells (Lipo) (S): 6S * ESC: 6S, 90A * Max Power (W): 2055.52 * Propeller: [Unknown or not specified]
