DarwinFPV Darwin129 FPV Drone - 280mm 7 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVL Quadcopters

DarwinFPV Darwin129 FPV Drone - 280mm 7 Inch F4 OSD 50A BLHeli_S Dshot600 800mW 1500TVL Quadcopters

RCDrone

Regular price $225.64 USD
Regular price $315.89 USD Sale price $225.64 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

29 orders in last 90 days

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

DarwinFPV Darwin129 FPV Drone SPECIFICATIONS

Video Capture Resolution: 720P HD

Type: HELICOPTER

State of Assembly: Almost Ready

Remote Distance: 2000

Remote Control: No

Recommend Age: 12+y

Power Source: Electric

Package Includes: Original Box

Package Includes: Camera

Origin: Mainland China

Operator Skill Level: Beginner

Operator Skill Level: Intermediate

Motor: Brushless Motor

Material: Carbon Fiber

Indoor/Outdoor Use: Indoor-Outdoor

Features: App-Controlled

Controller Mode: MODE2

Controller Mode: MODE1

Controller Battery: 3

Control Channels: 8 Channels

Camera Mount Type: Other

Brand Name: DarwinFPV

Aerial Photography: Yes

DarwinFPV Darwin129 FPV Drone, Gemfan Flash 7040 7 Inch 3 - DarwinFPV Darwin129 7Inch

Get 32% off the Jerwin DarwinFPV Darwin129, which comes with two pairs of Gemfan flash fans measuring 7 inches each.

DarwinFPV Darwin129 FPV Drone SPECIFICATIONS Video Capture
DarwinFPV Darwin129 FPV Drone, cnn.com: thank you for choosing our products and wish you a happy
DarwinFPV Darwin129 FPV Drone, 6.0g Darwin M80 GPS Item Nome:GPS+GLONASS

Welcome to DarwinFPV shop.We are the design team from China with rich design experience in the field of FPV racing drone. We aim to provide low-cost and high-performance products for every friend in the world who loves flying. Thank you for choosing our products and wish you a happy and safe flight

Item name:Darwin129

DarwinFPV Darwin129 FPV Drone, the flight controller supports Bluetooth function and can be connect to the mobile phone APP quickly .


Comeswithout battery,charger,receiverorremotecontroller.




Darwin129

Wheelbase:280mm

Framearmthickness:5mm

Framekitmaterial:3Kcarbonfiber

DrawinFPV

25071800KV 3-5S

Brushless Motor

Motor KV:1800KV

Idle Current (Io/10V):0.89A

Lipo Cell:3-5S

Weight:39g

Max Continuous Current:42A

Max Continuous Power:840W

Max thrust:1488g(4S/7")

Configu-ration:12N/14P

Motor Resistance (RM):0.0586 Ω

Stator Diameter:25mm

Stator Thickness:7mm

Motor Diameter:30.8mm

Motor Body Length:20mm

Overall Shaft Length:35mm

Prop adapter shaft:M5

Bolt holes spacing:16mm

Bolt thread:M3

Propeller:7”

4In1 50A Blheli_S ESC

F4-50A stack

Continuous current: 50A

Peak current: 60A (10S)

Lithium battery section number: 2-6S

BEC: 5V2A

ESC weight: 10.8g

Firmware: BL_S

Maximum support throttle signal: DSHOT600

Mounting hole: M3 30.5 * 30.5mm




F4FlightController


F4 Flight contro

Lithium battery section number: 3-6S

BEC: 10V 1A, 4.5V, 3.3V

MCU: STM32F405

Gyro: MPU6000

OSD: AT7456E

Firmware: MATEKF405

Weight: 7.2g

Mounting hole: M3 30.5 * 30.5mm

Support barometer, black box

Bluetooth





5.8G40CH800mw

VTXTX805P

Item name: FPV Transmitter VTX

Frequency: 5.8G Channels: 40CH

Input voltage: 7V~24V

5V camera supply: 120mA(MAX)----25mW@12V 5V

camera supply: 200mA(MAX)----200mW@12V 5V

camera supply: 300mA(MAX)----600mW@12V 5V

camera supply: 350mA(MAX)----800mW@12V Extra

features: Smart audio

Power supply: 5V output for Camera

Output power: 25mW/200mW/600mW/800mW

switchable Antenna connector: MMCX

Cable connector: Solder pads

Dimensions: 36mm*22mm*5mm,30.5 stackable hole

Weight: 8g(excluding antenna)

Darwin 19 camera

Item Name: B19

Resolution: 1500TVL

Lens: 2.1mm

TV System: NTSC & PAL (switchable)

DNR: 3DNR

Min. Illumination: 0.001LUX

Shutter Speed: PAL:1/50~100,000; NTSC: 1/60~100,000

Wide Power Input: 5-30V

Working Temperature: -20℃ ~ +60 ℃

Weight: 6.0g

Dimension: 19*19*19mm



Darwin M80 GPS

Item Nome:GPS+GLONASS

Power Supply:5V

Support Rate:115200dps

Receiving Sensitivity:Trace-167dBm Capture-160dBm

Size:18mm*18mm*7.1mm

Gemfan Flash 7040-3

Flash Durable 3 Blade

7040-Clear 2L2R

Material:PC

Mountinghole:5mm

Centerthickness:8mm

Quantity:1pairs

Weight:7.9g

Color:Black/Transparent Random

LipoBattery

Not included

Recommend4S

DarwinFPV Darwin129 FPV Drone SPECIFICATIONS Video Capture DarwinFPV Darwin129 FPV Drone, cnn.com: thank you for choosing our products and wish you a happy DarwinFPV Darwin129 FPV Drone, cnn.com: thank you for choosing our products and wish you a happy DarwinFPV Darwin129 FPV Drone, Nma#mke Lfatocaksina S8Us DarwinFPV Darwin129 FPV Drone, Darwin 19 camera Item Name: B19 Resolution: 1500TVL Lens: 2.1mm DarwinFPV Darwin129 FPV Drone, 6.0g Darwin M80 GPS Item Nome:GPS+GLONASS DarwinFPV Darwin129 FPV Drone, cnn.com: thank you for choosing our products and wish you a happy DarwinFPV Darwin129 FPV Drone, cnn.com: thank you for choosing our products and wish you a happy DarwinFPV Darwin129 FPV Drone, Darwin 19 camera Item Name: B19 Resolution: 1500TVL Lens: 2.1mm DarwinFPV Darwin129 FPV Drone, Darwin 19 camera Item Name: B19 Resolution: 1500TVL Lens: 2.1mm
