DSpower DS-E001E LEGO-Compatible Building-Block Servo, 180°/270° for Robot Projects

DSpower

$35.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Version DS-E001E(180°) DS-E001E(270°)

Quantity

View full details

Overview

The DSpower DS-E001E is a LEGO-compatible building-block servo for robotic, STEM education, creative, and small robot projects. Choose the DS-E001E(180°) or DS-E001E(270°) version to suit the required travel. The published electrical specification covers 6.0–9.0 V DC operation, while the 270° option is pictured with a double-concave cross output shaft and clutch protection.

Features

LEGO-compatible building-block servo for use with standard LEGO bricks or Technic elements.
Double-concave cross output shaft on the pictured DS-E001E(270°) version.
Clutch protection is described as protecting the gears if the output axle is turned violently.
Optional JR male to JST female adapter cable is identified for the DS-E001E.

Specifications

Parameter	Value
Operating Voltage	6.0–9.0 V DC
No Load Speed	≤0.20 sec/60° at 7.4 V
No Load Current	≤150 mA at 7.4 V
Stall Current	≤1.0 A at 7.4 V
Stall Torque	≥1.5 kgf·cm at 7.4 V
Pulse Width Range	500–2500 μs
Operating Travel Angle	270° ±10°
Mechanical Limit Angle	360°
Weight	29.5 ± 0.5 g
Case Material	ABS
Gear Set Material	POM
Motor Type	Core Motor

Available Versions

Version	Selection
DS-E001E(180°)	180°
DS-E001E(270°)	270°

The published operating-travel specification is 270° ±10°; select the version matching the travel required for the project.

Applications

Building-block and Technic projects: use the LEGO-compatible form factor with standard LEGO bricks or Technic elements for powered mechanisms.
STEM education and creative projects: select 180° or 270° travel for controlled movement in building-block assemblies.
Small robotic projects: the 180° version is presented for compact robot builds.
Robotics: listed application scenarios include humanoid robots, robotic arms, exoskeletons, quadruped robots, AGV vehicles, and ARU robots.
