Foxeer Datura 2105.5 1650KV 2950KV FPV Motor M3/M5 Prop Shaft

Foxeer Datura 2105.5 1650KV 2950KV FPV Motor M3/M5 Prop Shaft

Foxeer

Regular price $30.00 USD
Regular price Sale price $30.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

132 orders in last 90 days

KV

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

The Foxeer Datura 2105.5 FPV Motor is an advanced and durable motor option ideal for FPV enthusiasts, offering both 1650KV and 2950KV models to accommodate various performance needs.

Key Features:

  • Ultra-light Semi-hollow Titanium Shaft: The motor is built with a semi-hollow titanium shaft that reduces the weight without sacrificing the motor's strength, ensuring optimal durability for high-performance applications.
  • Military Grade High Temperature Winding: With a 260°C radiation-resistant stator, made of single crystal oxygen-free copper, the motor delivers high efficiency and reliability in demanding conditions.
  • N52H High-Quality Magnet: This high-performance magnet provides excellent power and surging energy, giving the motor a boost in responsiveness.
  • Excellent Shock Absorption: Equipped with an aluminum sheet and rubber ring, the motor offers impressive shock absorption for smoother flight performance.

Technical Specifications:

Specification 1650KV 2950KV
Configuration 12N14P 12N14P
Stator Diameter 21mm 21mm
Stator Length 5.5mm 5.5mm
Shaft Diameter 3mm (M3/M5 out) 3mm (M3/M5 out)
Motor Dimensions (Dia.*Len) Φ25.53*26.4mm Φ25.53*26.4mm
Weight 21g (with 3cm wire) 21g (with 3cm wire)
Idle Current (10V@10V) 0.6A 1.5A
Number of Cells (Lipo) 4-6S 3-4S
Max Continuous Power (3S) 413W 620W
Internal Resistance 190mΩ 60mΩ
Max Current (3S) 18.6A 37.9A
Max Efficiency Current (3S) (2-4A)>84% (2-4A)>84%

This motor is designed to deliver superior performance for FPV racing and freestyle flights, providing excellent power, durability, and thermal resistance. Whether you opt for the 1650KV version for smoother performance or the high-speed 2950KV variant, the Datura 2105.5 ensures high-quality operation across different flying conditions.

Foxeer Datura 2105.5 1650KV 2950KV FPV Motor, The Foxeer Datura 2105.5 motor is available in two options (1650KV and 2950KV) with features like M3/M5 prop shaft and a customizable aluminum sheath.

Foxeer Datura 2105.5 Motor, available in 1650KV and 2950KV options, features a M3/M5 prop shaft and a customized aluminum sheath.

Foxeer Datura 2105.5 1650KV 2950KV FPV Motor, Foxeer Datura motor features aluminum sheet, rubber ring, N5ZH magnet, military-grade components, single-crystal copper for shock absorption and high efficiency.

Foxeer Datura 2105.5 motor features aluminum sheet and rubber ring for excellent shock absorption, N5ZH high-quality magnet, and surging power. Military-grade components include radiation-resistant wire and high-temperature winding. Single-crystal oxygen-free copper ensures high efficiency.

Foxeer Datura 2105.5 1650KV 2950KV FPV Motor, The motor features shock absorption from an aluminum sheet and rubber ring for smooth flight.

Foxeer Datura 2105.5 1650KV 2950KV FPV Motor, Technical specifications for two identical motors with different KV ratings, including dimensions and configuration.
