Description
HPS-HC701– S.Bus2 High-Voltage Low-Profile cyclic Servo
High Performance cyclic Servo with Brushless Motor (1520uS/760uS switchable) (01102382-3)
FEATURES:
– Suitable for RC helicopters 500-800 3D/F3C
– Programmable/HV Brushless Servo.
– Custom New high power Brushless Motor.
– Supports 760uS (Factory Default, able to be set to 1520uS w/ GPB-1 v4.3 .)
– Programmable and compatible with S.Bus and S.Bus2 systems.
– Can be connected to a PC using the CIU-2/-3 USB adapter sold separately.
– Upper/middle/bottom: Aluminum Case
1520uS
Speed:0.07sec/60°(7.4V) / 0.08sec/60°(6.6V)
Torque:30.0gf・cm(7.4V) / 26.5kgf・cm(6.6V)
416.6ozf・in(7.4V) / 368.0ozf・in(6.6V)
760uS
Speed:0.07sec/60°(7.4V) / 0.08sec/60°(6.6V)
Torque:27.0kgf・cm(7.4V) / 24.0kgf・cm(6.6V)
375.0ozf・in(7.4V) / 333.3ozf・in(6.6V)
Dimensions/Weight:40.5×21.0×26.2mm/54g (1.59×0.83×1.03in)
RATED VOLTAGE:
DC 6.0V-7.4V
OPERATING VOLTAGE:
DC 4.8-8.4V
NO DRY BATTERY USE
