Futaba S3114 High Torque Nylon Gear Sub-Micro Servo 1.5Kg/cm 1.7Kg/cm

Futaba S3114 High Torque Nylon Gear Sub-Micro Servo 1.5Kg/cm 1.7Kg/cm

Futaba

Regular price $39.00 USD
Regular price Sale price $39.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

270 orders in last 30 days

If you have payment problems, pls refresh the page or "Chat with us".

Free Shipping: 10-20 days to arrive.

Express Delivery: 6-14 days to arrive.

Warehouse: China/USA/Europe, Can delivery to all countries, tax included.

Free shipping & User guarantee

  • Free Shipping:Ships within 3days, arrives within 10-18 days
  • Paid Express: Ships within 2days,arrives within 4-7 days
  • Money back guarantee: Quality problems, return and exchange within 30 days
  • 12-month warranty, long-term after-sales service
  • No need to register account, Order tracking url will send to your email
  • More FAQ:FAQ

The S3114 servo is a micro servo for small electronic powered models. Pay special attention to the following points:

  • Do not use with gas powered engine models or other models that require high torque.
  • Using supply voltage higher than 6.0V or applying high loads to the servo will shorten the life.
  • Always use the servo horn specifically designed for this micro servo. Do not use conventional servo horns.
  • Excessive force or shock to the servo horn may damage the ultra mini precision gears inside the servo.

S3114 High Torque Nylon Gear Sub-Micro Servo from Futaba - FUTM0414

The S3114 high torque sub-micro is a basic servo that works well for 1400mm wingspan and smaller airplanes, small EDF jets, and 200 to 450 size helicopters.

Features:

  • Quality basic servo perfect for 1400mm and smaller airplanes and small EDF jets
  • High torque
  • Ideal for electric planes and small electric helis
  • Nylon gears
  • One year warranty

Includes:

  • 1x S3114 high torque sub-micro servo
  • 1x .91" x .64" (23mmx16mm) 4 arm servo horn (comes pre-installed)
  • 1x 1.33" x 1.33" (34mmx34mm) 4 arm servo horn
    Servo Measurement Key

    Product Specifications:

    Servo Class

    Sub-Micro

    Servo Type

    Analog

    Gear Material

    Nylon

    Direction

    Standard / Normal

    Operating Voltage Range

    4.8V to 6V

    Speed (4.8V)

    0.10 sec @ 60 deg

    Speed (6V)

    0.09 sec @ 60 deg

    Torque (4.8V)

    1.5 kg/cm (21 oz/in)

    Torque (6V)

    1.7 kg/cm (24 oz/in)

    Current Draw at Idle

    8 mA

    Current Draw Operating (No Load)

    N/A

    Dimensions (L x W x H)

    22 x 11 x 20mm

    Weight

    7.8g (0.28oz)

    Lead Length

    304.8mm / 12in
