Overview
The Futaba S9372SV is a high-performance programmable surface servo designed for competitive RC cars. Featuring S.Bus2 technology, ultra-fast response, and exceptional torque, this high-voltage servo is ideal for precision steering and throttle applications. With a durable build and wide voltage tolerance, it delivers superior performance under demanding conditions.
Key Features
-
S.Bus2 Compatible – Allows flexible, programmable settings and superior response.
-
High-Speed Precision – Achieves 0.06 sec/60° at 7.4V, perfect for fast response control.
-
Powerful Torque Output – Delivers up to 24.6 kgf·cm (341.7 ozf·in) at 7.4V.
-
High-Voltage Ready – Supports 6.0V to 7.4V rated voltage with operating range from 4.0V to 8.4V.
-
Durable & Compact Design – Compact size with 70g weight, built for reliability in tight builds.
Specifications
| Specification | Value |
|---|---|
| Model Number | 01102267-3 |
| Speed @ 6.0V | 0.07 sec/60° |
| Speed @ 7.4V | 0.06 sec/60° |
| Torque @ 6.0V | 20.0 kgf·cm / 277.8 ozf·in |
| Torque @ 7.4V | 24.6 kgf·cm / 341.7 ozf·in |
| Dimensions | 40.5 × 21 × 37.4 mm (1.59 × 0.83 × 1.47 in) |
| Weight | 70 g (2.47 oz) |
| Rated Voltage | DC 6.0V – 7.4V |
| Operating Voltage | DC 4.0V – 8.4V |
| Battery Compatibility | No dry battery use |
