Overview
The GEPRC GR1102 Brushless FPV Motor is designed for high-efficiency micro drone builds, especially 2.0 to 2.5 inch toothpick and whoop frames. Available in 9000KV, 10000KV, and 14000KV, and supporting 1S to 3S LiPo/LiHV, it offers flexible power for indoor cruising, freestyle flying, or lightweight HD setups.
Featuring an ultra-light 3.2g construction, precision NSK bearings, and optional 1.0mm or 1.5mm shaft diameters, the GR1102 delivers responsive thrust with smooth, balanced operation. It comes in both 3-hole and 4-hole mounting options to fit a wide range of frames and propellers.
Key Features
-
Available in 9000KV / 10000KV / 14000KV for 1S–3S power setups
-
Compatible with 2.0 to 2.5 inch props, including 1.6" 4-blade or 2.5" 2-blade
-
Ultra-lightweight design at 3.2g with wire
-
Optional 1.0mm or 1.5mm shaft for prop flexibility
-
Supports 3-hole or 4-hole mounting pattern
-
Built-in NSK bearings for smooth performance and long durability
-
Ideal for whoop and toothpick frames focused on agility and efficiency
Specifications
Parameter | Value |
---|---|
Model | GR1102 |
KV Rating | 9000KV / 10000KV / 14000KV |
Configuration | 9N12P |
Stator Size | 11mm × 2mm |
Motor Dimensions | Φ13.8mm × 15mm |
Shaft Diameter | 1.0mm or 1.5mm (optional) |
Mounting Pattern | 3-hole or 4-hole (M1.4) |
Weight | 3.2g |
Voltage Support | 1S–3S LiPo / LiHV |
Propeller Support | 1.6 inch to 2.5 inch |
Package Includes
-
1 × GEPRC GR1102 Brushless Motor

GEPRC GR1102 Motors: 9000KV/10000KV, 3-hole or 4-hole design, shaft diameter 1mm or 1.5mm, compatible with 10kv GRI102 Whoop Frame, featuring 2-blade props with a prop size of 1.6 inches and 1.5mm shaft diameter.
