iFlight SucceX Force VTX Video Transmitter - 5.8GHz 25mW / 100mW / 400 mW / 600mW VTX Adjustable for FPV Racing drone part DIY Accessory

 REMARK:it support 20*20/25.5*25.5

Description：

Features:

• The output power is stable;
• Transmit power 4 gear switch: 25mW/100mW/400mW/600mW;
• Output 40 channels.
• Frequency lock fast, the boot does not interfere with companions;
• Built-in output power self-check function;
• Full format video format: NTSC /PAL;
• Wide input voltage range. low power consumption: 6V～36V
• Small size:36*36*3mm
• Mounting holes 4-M3
• Lightweight: 7.2g(excluding antenna)

Specs:

• Item: SucceX-Force 600mW adjustable VTX
• Input voltage: 6-36V
• Output voltage/ Max current: 5V±0.5V 1A
• Channel: 40
• size:36*36*3mm
• PIT/25mW/100mW/400mW/600mW

Package included:

• SucceX Force 600mW adjustable VTX x 1pc
• MMCX to SMA Female Adapter Cable 100mm x 1pc
• 5.8GHz MMCX straight antenna 65mm x 1pc
• SH1.0 6P cable 100mm x 1pc
