JX Servo PDI-6208MG SPECIFICATIONS
Brand Name: NoEnName_Null
Origin: Mainland China
Material: Composite Material
RC Parts & Accs: Digital Servo
Size: 40.5X20.2X40mm
For Vehicle Type: Airplanes
Use: Vehicles & Remote Control Toys
Upgrade Parts/Accessories: Servo
Remote Control Peripherals/Devices: Remote Controller
Tool Supplies: Assembly Category
Quantity: 1 pcs
Technical parameters: KV1100
Model Number: JX Servo PDI-6208MG
Four-wheel Drive Attributes: Assemblage
Wheelbase: Bottom Plate
Features:
High performance digital standard servo
High-precision aluminium gears with hard anodizing
CNC aluminium middle Shel
Dual ball bearings
Specifications:
Item Number:PDI-6208MG
Dead -band: 2μs
Working frequency: 1520μs / 330hz
Operating Speed (4.8V): 0.09 sec/60°
Operating Speed ( 6V): 0.07 sec/60°
Stall Torque (4.8V): 6.8 kg.cm ( 239.86oz/in )
Stall Torque (6V): 8.2 kg.cm ( 289.25oz/in )
Dimensions: 40.5X20.2X40mm /1.59 X0.80X49 in
Weight: 55.6g ( 1.96oz )
Steering angle: 0-120 degree
Connector Wire Length: JR 260 mm
Bearing: 2BB
Usage: For RC Models
Package Included:
1 * PDI-6208MG Servo
