RadioMaster TX12 MKII SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Universal Joint

Tool Supplies: Battery

Technical parameters: KV1100

Size: 170*159*108mm

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 12+y

RC Parts & Accs: Radio Systems

Quantity: 1 pcs

Origin: Mainland China

Model Number: TX12 MKII

Material: Composite Material

Four-wheel Drive Attributes: Battery

For Vehicle Type: Airplanes

Brand Name: abay

Mode 1-Right-hand throttle

Mode 2-Left hand throttle

TX12 MKII Feature:

• Size： 170*159*108mm

• Weight： 363g

• Frequency： 2.400GHZ-2.480GHZ

• RF Chip： ExpressLRS (ELRS)/CC2500 MPM

• Transmitting Power： 20dbm

• Antenna Gain： 2db

• Working Current： 320mA@8.4V

• Voltage Range：6.6-8.4v DC

• Range： > 2km (depending on receiver)

• Radio Firmware： EdgeTX (Transmitter) / ExpressLRS (RF module)

• Channels： Up to 16 (depending on receiver)

• Display：128*64 Monochrome LCD display

• Gimbal： High precision hall gimbals

• External module：JR/FrSKY/Crossfire compatible

• Upgrade Method： USB/SD card & EdgeTX Buddy online or EdgeTX Companion PC software

• USB Charging: QC3 USB-C

• SD Card: Included

IMPROVEMENTS

New to TX12 MKII ELRS Version

• Updated rear case with comfortable grips

• Improve S1 / S2 Grips

• Improved USB-C QC 3.0 Charging

• Updated main board design

• Updated MCU STM32F407

• EdgeTX factory installed

• SD Card included

• Internal ExpressLRS RF Module

New to TX12 MKII CC2500 Version
★ Updated rear case with comfortable grips
★ Improve S1 / S2 Grips
★ Improved USB-C QC 3.0 Charging
★ Updated main board design
★ Updated MCU to STM32F407
★ EdgeTX factory installed
★ SD Card included

Find out more about the Opensource projects that drive our radios.
http://edgetx.org/
https://www.open-tx.org/
https://www.multi-module.org/

ExpressLRS 2.4ghz RF Module Worleng 130-18Oma 310-350ma Working 6.6-8.4V DC Voltage Upgrode USBISD card & EdgeTX Companion . 2x 18650 (18650 tray included) Battery 21700 2s 7.4v SOOmAh maximum .

Aniennl Handcl Truintr Pont TYPE C USB SE Posion Posttkn 1591mm7 108rnrnt Doamen SCpordin EBron Snbnmn Slacr Pot Slc Pot Lei Gnhal Rioh: G mbal Polcr Humtton 17000 Sys Builon VOL Burcn Butonz FlBtrion PAGE > Button Weru Teci PiGE

MGHTY MNT RADTO Added internal ExpressLRS/ CC25O0 module support Main processor upgraded from STM32F207 to Stm32F407 RELUBaaSitR 'TX12 Improved USB-C charge IC with QC3.0 support Precision hall-effect gimbals as standard EdgeTX operating system installed from factory Rear case improved with ergonomic grips Improved S1 / S2 slider grip SD Card included

TX12 Mark II ELRS CC2500 HALL Gimbals OPEN T EDGETX_ AND OPENTXSUPPORT Main processor upgraded from STM3ZF2O7 to STM32F4O7 . Rear case improved with ERGONOMIC GRIPS IMPROVED S1/52 SLIDER GRIP Data TRS 3.siim USB-C Port Trainer Socket | 8sn osa SUPPORTS USB SIMULAVORS
