RadioMaster TX16S Mark II Max Radio Controller M2 ELRS-V4 Hall Gimbal Radio Control Hall Gimbals Drones Airplane Multi-protocol

RadioMaster TX16S Mark II Max Radio Controller M2 ELRS-V4 Hall Gimbal Radio Control Hall Gimbals Drones Airplane Multi-protocol

RadioMaster

Regular price $367.81 USD
Regular price $514.93 USD Sale price $367.81 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

26 orders in last 90 days

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Recommend Age: 12+y,14+y

RC Parts & Accs: Transmitters

Origin: Mainland China

Model Number: TX16S MAX Radio Controller

Material: Plastic

Certification: CE

Description

built-in charger features over current protection and temperature sensors to ensure safe charging

Specification

  • Type: TX16S MAX Radio Controller
  • Size: 286.9*128.9*183.8mm
  • Weight: 750g (without battery)/820g (with 2 x 18650 batteries installed)
  • Voltage: DC7-8.4V
  • Battery: 2 x 18650 (tray supplied) or 2S lipo (batteries not included)
  • Current: 350mah (NO CRSF)
  • Channel: 16ch
  • External Micro SD slot: Card Included
  • 2 x External UART Expansion Ports
  • Touch Panel installed (Requires OpenTX/EdgeTX 2.4 Update)

Features

  • STM32F429BIT6 MCU
  • Industrial grade 4.3 inch IPS 480*272 Screen with touch
  • Compatible with OpenTX
  • Wheel menu button
  • Full size HALL sensor gimbals with CNC Aluminum Facia.
  • Internal Multi-protocol RF System
  • Native Full Speed TBS Crossfire support (400K)
  • Supports Telemetry (Protocol and Receiver dependent)
  • Memory 16M (can be expanded by Micro SD card)
  • Voice function
  • Vibration reminder function
  • Improved JR module slot
  • 6-Flight Mode Buttons (Pixhawk, custom functions and more!)
  • Three-color LED status display
  • USB-C Charging port.
  • USB-C Simulator and PC connection port.
  • External UART ports to expand the capabilities of your radio.
  • CNC option parts and leather grips factory fitted.
  • Neck Strap included

Internal Multi-protocol RF

The TX16s internal RF system features the CC2500, NRF24L01, A7105 and CYRF6936 RF Chip modules all integrated on one board. This module most of today prominent RF protocols (See RF Chip data below). The RadioMaster internal RF module will support firmware updates directly from the radios Operating system.

cypress Semiconductor CYRF6936 MULTI DSM/

OpenTX Supported

RadioMaster has worked in collaboration with OpenTX to bring the TX16s into the market and will continue to work with OpenTX to provide support to the project and ensure the concepts of open standards are carried forward today and in the future.

Bigger is Better Extra-large battery compartment

HALL Sense Gimbals

The high-quality precision Hall Sensor gimbals with CNC Aluminium Facias provide the ultimate experience in this class of radio.

Hall Sensor gimbals CNC Aluminium Facias Exterior Adjustable 800 3j

4.3- IPS Color Display

The TX16s features a bright and clear 4.3-inch IPS color display for easy and convenient model setup and operation with adjustable brightness to suit all conditions.

* Touch Panel included with TX16S Hall and TX16S Hall MasterFire combo only. Touch functionality requires OpenTX 2.4 (coming soon). TX16S Standard version is Touch Panel ready and can be upgraded with optional touch panel sold separately.

built in Touch Panel ready for future updates of OpenTX Firmware* .

External Module Bay

The TX16s natively supports Team Black Sheep MicroTX modules in CRSFmode with LUA scripts. Best of all the TX16s Internal 4-in-1 Multi-protocol module allows you to keep the MicroTX installed and switch between internal RF and Crossfire via software, no more module swapping.

the official MasterFire combo gets you in to the Crossfire action right out of the box

High-Density Foam Case

The included storage box is made from high-density shockproof EPP foam. Ideal for safe storage and transport of your TX16s.

built-in charger features over current protection and temperature sensors to ensure safe charging

Convenient Charging

The TX16s features built-in USB-C charging with a 2s Battery Management System to balance charge 7.4v Li-ion or Li-Poly batteries. Our built-in charger features over current protection and temperature sensors to ensure safe charging.

TX16S Standard version is Touch Panel ready and can be upgraded with optional touch panel sold

Bigger is Better

Extra-large battery compartment. Built-in USB-C charging for 2 * 4.2V Li-lon batteries or 2 cells li-poly battery.

Height: 25mm Length: 97mm 2 X 18650 included width:

Anti-slip Rubber Grips

Balanced ergonomics provide the ultimate grip and comfort for hours of use.

Anti-slip Rubber Grips Balanced ergonomics provide the ultimate and comfort for hours of

Easy Firmware Updates

Program all your model and radio settings from your PC with OpenTX Companion PC software

130°Folding Handle

1309 Folding handle Included in the box: 1309 Traditional metal handle or folding handle

Radio Overview

Antenna Handel S1,S2 Dail Pos Buttons SF 2

Antenna Handel S1,S2 Dail Pos Buttons SF 2 Position SH Momentary SE 3 Position SG 3 Position SB 3 Position SC 3 Position SA 3 Position SD 3 Position RO DFASTE LS Slider Pot Speaker TXigS Gimbal Power Button Lanyard Loop T1-T16 Trim Button MDL Button RTN Button PAGE> Button Menu Wheel PAGE Button TELE Button 4.3"

GIMBAL MODE SETTING STICK TRAVEL LIMITER Turn clock

Radio Size

RaqiolasieR TKks 212mm 66 183mm

Package Includes

  • 1 * TX16S MAX Radio Controller
  • 1 * 18650 tray
  • 1 * USB-C cable
  • 1 * Neck Strap
