• Raspberry Pi Zero W Single-Board Computer, BCM2835 1GHz, 512MB LPDDR2, Wi‑Fi 802.11n, Bluetooth 4.1, Mini HDMI, 40‑pin GPIO
  • Raspberry Pi Zero W Single-Board Computer, BCM2835 1GHz, 512MB LPDDR2, Wi‑Fi 802.11n, Bluetooth 4.1, Mini HDMI, 40‑pin GPIO
  • Raspberry Pi Zero W Single-Board Computer, BCM2835 1GHz, 512MB LPDDR2, Wi‑Fi 802.11n, Bluetooth 4.1, Mini HDMI, 40‑pin GPIO
  • Raspberry Pi Zero W has a BCM2835 1GHz processor, 512MB memory, Wi-Fi, Bluetooth, Mini HDMI, and 40-pin GPIO header.
  • Raspberry Pi Zero W V1.1: compact 2017 board with Wi-Fi, Bluetooth, Mini HDMI, GPIO; BCM2835 CPU, 512MB RAM; FCC/CE compliant; for wireless computing. (24 words)
  • Raspberry Pi Zero W with GPIO, Wi-Fi, Bluetooth, and Mini HDMI
1 7

Raspberry Pi Zero W Single-Board Computer, BCM2835 1GHz, 512MB LPDDR2, Wi‑Fi 802.11n, Bluetooth 4.1, Mini HDMI, 40‑pin GPIO

Raspberry Pi Zero W Single-Board Computer, BCM2835 1GHz, 512MB LPDDR2, Wi‑Fi 802.11n, Bluetooth 4.1, Mini HDMI, 40‑pin GPIO

Raspberry Pi

$39.00 USD
$39.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Options
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
View full details

Overview

The Raspberry Pi Zero W is a compact single-board computer designed for embedded, IoT, and automation projects. Measuring 65mm × 30mm × 5mm and weighing 9g, it integrates 2.4GHz 802.11b/g/n Wi‑Fi and Bluetooth 4.1 (BLE), provides a HAT‑compatible 40‑pin GPIO, and uses a microSD card for storage. The platform is powered by the Broadcom BCM2835 with a 1GHz single‑core CPU and 512MB LPDDR2 SDRAM, supporting Raspberry Pi OS for lightweight Linux applications.

Key Features

  • Compact Linux development board at 65mm × 30mm × 5mm, 9g
  • Ready-to-use: mounted with headers and ready for deployment
  • Wireless connectivity: built‑in 2.4GHz 802.11n Wi‑Fi and Bluetooth 4.1 (BLE)
  • 40‑pin GPIO compatible with Raspberry Pi HATs, sensors, and actuators
  • 512MB LPDDR2 SDRAM; microSD card as primary storage

Specifications

Processor Broadcom BCM2835
CPU Frequency 1GHz, single‑core
Memory 512MB LPDDR2 SDRAM
Wireless – Wi‑Fi 2.4GHz IEEE 802.11b/g/n
Wireless – Bluetooth Bluetooth 4.1, BLE
Video – HDMI Mini HDMI
Video – Camera CSI camera connector (v1.3 only)
USB Micro USB On‑The‑Go (OTG) port
GPIO Header HAT‑compatible 40‑pin header
Additional Headers Composite video and reset headers
Power Port Micro USB power port
Input Voltage 5V DC
Recommended Current 2.5A
Operating Temperature ‑20°C to +70°C
Dimensions 65mm × 30mm × 5mm
Weight 9g
Storage microSD card (primary storage)

Applications

  • Internet of Things (IoT) projects
  • Home automation
  • Portable and battery‑powered builds
  • Robotics and general automation
  • Remote monitoring and surveillance

Documents

ECCN/HTS

HSCODE 8471504090
USHSCODE 8517180050
EUHSCODE 8471800000
COO JAPAN
UPC

What’s Included

  • Raspberry Pi Zero W × 1

Details

Raspberry Pi Zero W, Compact Linux development board for IoT projects, home automation, and robotics.The Raspberry Pi Zero W is a compact single-board computer.
