Beginner Electric Sonicmodell AR Wing Pro RC Airplane SPECIFICATIONS
Warranty: as show
Warning: as show
Video Capture Resolution: Other
Type: Airplane
State of Assembly: Almost Ready
Remote Distance: as show
Remote Control: No
Recommend Age: 12+y
Power Source: Electric
Plugs Type: as show
Package Includes: Original Box,Operating Instructions,Other
Origin: Mainland China
Operator Skill Level: Beginner,Intermediate,Expert
Model Number: as show
Material: Metal,Plastic,Rubber,Foam
Indoor/Outdoor Use: Outdoor
Flight Time: as show
Features: Other,App-Controlled
Dimensions: 100cm-150cm
Controller Mode: MODE2
Controller Battery: as show
Control Channels: 4 Channels
Charging Voltage: as show
Charging Time: as show
Certification: CE
Camera Mount Type: Other
Brand Name: EACHINE
Barcode: No
Aerial Photography: No
Description:
Brand Name: Sonicmodell
Item Name: AR Wing Pro
Material: High Quality EPP
Wingspan: 1000mm (39.37'')
Length: 450mm (17.71'')
Wing Area: 18dm?
Version: KIT, PNP(optional)
KIT Empty Weight: 340g
PNP Empty Weight: 500g
Recommended Sonicmodell Power Combo Configuration:
Motor: 2216-1400KV
ESC: 40A w/5V 3A BEC
Servos: 2pcs 9g metal gear servo
Propeller: 2 blades 8x5
Recommended Battery: 4S 3200-3500mAh Lipo, ZOHD Lionpack 18650 4S2P 7000mAh
Recommended Flying Capability:
Min. recommended Speed: 31km/h
Max. Speed (with SM power combo): 130km/h
Cruise Speed (with Sonicmodell power combo): 75/80km/h @ 5.5A
Max. Speed Tested Without Structural Failure: 220km/h with no structural damage or twist on elevons
Max. Recommended Takeoff Weight (with SONICMODELL power combo): 1425 grams
Reflex On Elevons: 1.5-2mm at level
Recommended Max. Throws: 12mm
Features:
- The World 1st FPV Wing with dedicated nose camera bay and main hatch bay for DJI HD Air Unit System, no need any cut or DIY to fit the DJI System.
- Aerodynamic designed FPV pocket in both sides of fuselage, with high efficient NACA air cooling system to ensure the FPV gear work in perfect condition.
- Molded by tough EPP material, built-in CF spar for enhancement, super stable flying capability and crash resistance.
- Extra nose and side camera bay and main hatch that compatible with all FPV and AIO cameras in the market.
- Nose camera slot compatible with all HD Auction cameras (for Gopro, DJI, Runcam etc) in the market.
- Multiple tunnels inside all quipment bays, easy to layout wire between each bay.
- Detachable main wing and wing tip, glue-free assembly, portable for outdoor flying.
- Built-in CF rod in the ailerons will give precision and sharp action to your inputs.
- High accurate ball link control system brings agile and quick response in control.
- Special-designed “servo arm built-in” structure will protect your servo arm from impact.
- Large battery bay for extended flight time and more rooms for various Flight Controller.
- Decent rear bay for ESC, isolate interference from other FPV equipment.
- Built-in plate inside fuselage for extra enhancement.
- Extra CA Hinges for DIY will bring you more stiff and agile control.
- Optimized air-cooling design will keep your gear safe from overheating.
English Manual:
http://myosuploads3.banggood.com/products/20201229/20201229194812ARWingProManual.pdf
KIT Includes:
SONICMODELL AR Wing Pro KIT with all hardware.
KIT Package Size: 42*31*15.5cm
KIT Package Weight: 1200g
Note: Motor,esc, servos, propeller, battery, charger, transmitter and receiver are not included.
PNP Includes:
SONICMODELL AR Wing Pro KIT with power combo (uninstalled motor, esc, servos, propeller, and hardware.)
PNP Package Size: 42*31*15.5cm
PNP Package Weight: 1500g
Note: Battery, charger, transmitter and receiver are not included.
somic MODELL ARWING PRO Details: Two main hatches will add flexibility for deployment Fn So Rziuds FSOd FRzuo
you still have the classic under-wing pockets to keep adding gear . if all the in-fuse space offered was not enough, there are still the under-
somic MODELL ARWING PRO Install your DJI Camera without removing the cable with the dedicated DJI nose cone
somic MODELL ARWING PRO Details: 37mm 53mm | Generous space for your gear 8 l10mm 138mm
somic MODELL ARWING PRO Features: CF reinforcements for ailerons, CA hinges and ball link control rods . a premium feel
somic MODELL ARWING PRO Details: Original design for Air-cooled side pockets will keep even the hottest VTX nice and cool 65mm 55mm euos H3Omm T7300w 65mm 25Smm (30
somic MODELL ARWING PRO Details: Install any classic HD camera without compromising aerodynamics 00r
Sonic 9 Mdofii Motor: 2216-1400KV ESC: 40A wISV 3A BEC Servos: Zpcs 9g metal gear servo Propeller: 2 blades 8x5 Recommended Battery: Lipo 4S 3200-3500mAh ZOHD Lionpack 18650 4S2P 700OmAh
somic MODELL ARWING PRO Performance and Recommended Limits: Min. recommended speed: 31kmlh Max. speed (with SONICMODELL power combo): 130 kmlh Cruise speed: 75/80km/h 5.5A Max Speed tested without structural damage or twist on elevons Max recommended takeoff weight: 1425 grams Reflex on elevonics: 1.5-2mm at level Recommended max.
somic MODELL ARWNG PRO Gallery: KGOBfLf 15c Jrmir [ MObl( LawUII The Nely @ENCHMAAK n Kicoa Adavh Doit Fox
SONICMODELLAR PRO KIT includes: BASIC power combo (uninstalled motor; esc, servos, propeller; and hardware .) Available soon: _ Dkit DPkP Wing Tev uaca Wo?
