iFlight Albatross V2.1 5.8GHz FPV Antenna 130mm RG141 RHCP SMA / LHCP RP-SMA (2pcs)
iFlight Albatross V2.1 5.8GHz FPV Antenna 130mm RG141 RHCP SMA / LHCP RP-SMA (2pcs)
iFlight
Regular price
$23.17 USD
Regular price
Sale price
$23.17 USD
Unit price
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Overview
iFlight Albatross V2.1 is a 5.8GHz FPV antenna featuring an upgraded rugged hexagonal design and a right-angle form for easier fixation. V2.1 uses upgraded welding technology to reduce weight while improving attachment security and consistency.
Key Features
- Hexagonal shape for enhanced durability; right-angle design for convenient fixation
- Ultrasonic welding technology for a lightweight, secure antenna attachment
- Improved consistency in antenna gain to support stable performance
- Polarization options and connectors covered by provided specs: RHCP SMA and LHCP RP-SMA
- Note for DJI Digital FPV use: RP-SMA LHCP is referenced; both sides should match polarization
Changelog
- July 17, 2025: Upgraded to version 2.1, using LDS technology; stated to provide more stable performance than V2.
Specifications
RHCP Specifications
| Model | Albatross 5.8GHz RHCP SMA FPV Antenna |
| Interface | RHCP SMA |
| Frequency range | 5.3GHz-6GHz |
| Max Gain | 2.85dBi (5695MHz) |
| MIN Gain | 2.9dBi (5362MHz) |
| AVG Gain | 2.9dBi |
| MAX VSWR | 1.76 (6000MHz) |
| MIN VSWR | 1.20 (5300MHz) |
| AVG VSWR | 1.48 |
| MAX radiation efficiency | 68.77% (5700MHz) |
| MIN radiation efficiency | 65.17% (5300MHz) |
| AVG radiation efficiency | 66.51% |
| Polarization | RHCP |
| Cross polarization suppression | -25dB |
| Axial Ratio | <= 3 |
| Cable | RG141 |
| Weight | 10.5 +/- 0.5g |
| Size | Total length: 130mm (+/- 5mm) |
LHCP Specifications
| Model | Albatross 5.8GHz LHCP RP-SMA FPV Antenna |
| Interface | LHCP |
| Frequency range | 5.3GHz-6GHz |
| Max Gain | 3.05dBi (5621MHz) |
| MIN Gain | 2.88dBi (5436MHz) |
| AVG Gain | 2.92dBi |
| MAX VSWR | 1.74 (5700MHz) |
| MIN VSWR | 1.19 (5300MHz) |
| AVG VSWR | 1.5 |
| MAX radiation efficiency | 68.89% (5500MHz) |
| MIN radiation efficiency | 64.51% (5300MHz) |
| AVG radiation efficiency | 66.82% |
| Polarization | LHCP |
| Cross polarization suppression | -25dB |
| Axial Ratio | <= 3 |
| Cable | RG141 |
| Weight | 10.5 +/- 0.5g |
| Size | Total length: 130mm (+/- 2mm) |
What’s Included
- 2 x Albatross V2.1 5.8GHz 100mm Antenna
Notes
- FPV frame not included.
- The provided package list states “100mm Antenna”, while the provided specifications list total length as 130mm (tolerance varies by polarization).
For installation or compatibility questions (connector type/polarization matching), contact support@rcdrone.top or visit https://rcdrone.top/.
