MAD VC 15x20 Inch Carbon Fiber Propeller 1pc (VC 15x20-R) Voyager Carbon Series, 325g
MAD VC 15x20 Inch Carbon Fiber Propeller 1pc (VC 15x20-R) Voyager Carbon Series, 325g
MAD
Regular price
$73.50 USD
Regular price
Sale price
$73.50 USD
Unit price
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
Overview
MAD VC 15x20 is a Voyager Carbon Series carbon fiber propeller designed for drone/RC aircraft propulsion, featuring a professional matte fiber surface. The 15x20 inch format (381 x 508 mm) is built with CF+epoxy construction and a matte frosting surface treatment.
Key Features
- Voyager Carbon Series; 15x20 IN, professional matte fiber
- CF+Epoxy material with matte frosting surface treatment
- Single weight: 3285 g
- Recommended thrust: 1.7~4 kg; recommended max thrust: 17 kg
- RPM range (listed): 48007000 RPM
Specifications
| Series | Voyager Carbon Series |
| Model | VC 15x20-R |
| Size | 15x20 in |
| Dimensions | 381 x 508 mm |
| Single Weight | 3285 g |
| Material | CF+Epoxy |
| Surface Treatment | Matte frosting |
| Working Temp | -40C~65C |
| Storage Temp | -10C~50C |
| Storage Humidity | <85% |
| RPM | 48007000 RPM |
| Recommend Thrust | 1.7~4 kg |
| Recommend Max Thrust | 17 kg |
| Prop Drawing (length) | 381 |
| Center Hole | 8 |
| Prop Drawing (thickness) | 15.80.5 |
Test Data
| RPM | Thrust (gf) | Torque (Nxm) | Output Power (w) | Efficiency (gf/w) |
|---|---|---|---|---|
| 1628 | 159 | 0.13 | 22.0 | 7.2 |
| 2439 | 411 | 0.32 | 82.8 | 5.0 |
| 3265 | 778 | 0.58 | 199.0 | 3.9 |
| 4022 | 1236 | 0.89 | 373.2 | 3.3 |
| 4753 | 1772 | 1.25 | 623.7 | 2.8 |
| 5497 | 2416 | 1.70 | 978.0 | 2.5 |
| 6226 | 3118 | 2.17 | 1417.4 | 2.2 |
| 6888 | 3763 | 2.61 | 1879.7 | 2.0 |
| 7519 | 4396 | 3.06 | 2410.2 | 1.8 |
Whats Included
- VC 15x20-R propeller 1 piece
Applications
- Drone/RC aircraft propulsion setups requiring a 15x20 inch carbon fiber propeller
For compatibility questions (hub size, rotation direction, and motor pairing), contact support at https://rcdrone.top/ or email support@rcdrone.top.
Details
Voyager Carbon Series 15x20 in carbon fiber propeller features a matte finish and a 381 mm overall length for consistent fitment.
