SteadyWin WK1105 Motor 12V Compact 6Pairs 50T, 1505rpm/v, Ø14.9*6.25mm, 6g

SteadyWin

$40.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Version WK1105 Ring Magnet Rotor

Quantity

View full details

Overview

SteadyWin WK1105 Motor is a compact motor designed for robotics and mobile automation projects, including humanoid robots, robotic arms, exoskeletons, quadruped robots, AGV vehicles, and ARU robots.

Key Features

Nominal voltage: 12V
Speed constant: 1505rpm/v
Compact size: Ø14.9*6.25mm; weight: 6g
6Pairs pole pairs; 50T winding turns
Working temperature: -20~80℃ (max demagnetize tempersture: 120℃)

Specifications

Nominal voltage	12V
Nominal current	0.59A
Nominal torque	0.01N.M
Nominal speed	850rpm
Max speed	18057rpm
Stall torque	0.01 N.m
Stall current	0.92A
Winding turns of motor	50T
Interphase resistance	12.5Ω
Interphase inductance	1.15Mh
Speed constant	1505rpm/v
Torque constant	0.01N.M/A
Rotor inertia	1gcm^2
Number of pole pairs	6Pairs
Working temperature	-20~80℃
Max demagnetize tempersture	120℃
Inner diameter of the stator	5mm
Motor size	Ø14.9*6.25mm
Motor weight	6g

Applications

Humanoid robots
Robotic arms
Exoskeletons
Quadruped robots
AGV vehicles
ARU robots

Manuals / Documents

For technical support or pre-sales questions about selecting and integrating the WK1105 Motor, contact support@rcdrone.top or visit https://rcdrone.top/.
