Tarot HDMI to Analog AV Module - 300mm Open Type (TL3503)

Product Overview:

The Tarot HDMI to Analog AV Module is a high-performance video signal conversion accessory developed specifically for drone applications. It enables seamless conversion from HDMI to analog AV, ensuring smooth, clear video transmission with minimal delay. Designed for use in various professional and recreational drone setups, this compact and lightweight module weighs only 17g, making it an ideal choice for UAV systems that prioritize efficient space and weight management.

• Input Voltage: 10-30V for wide compatibility.
• Delay: Minimal latency of just 60 milliseconds.
• HDMI Cable Length: 300mm, with optional customization.
• Weight: Only 17g for easy integration into drone setups.
• Size: 40.5mm × 19.4mm × 12.2mm.

Product Parameters:

Key Features:

• High-Performance Conversion: Converts HDMI signals to analog AV, ensuring clear and consistent video output for drone applications.
• Compact and Lightweight Design: Weighs just 17g, making it perfect for drones where space and weight are critical.
• Low Latency: Enjoy real-time video output with a delay of only 60 milliseconds, minimizing any disruptions during flight operations.
• Durable and Reliable: Built to operate within a wide temperature range of -20°C to 50°C, ensuring stability in various environments.
• Customizable Cable Length: The module comes with a 300mm HDMI cable as standard but can be upgraded to 500mm or customized to other lengths based on user needs.
• Easy Integration: Designed to work seamlessly with Tarot’s TL10A11 series adapters, offering greater flexibility in connecting to various devices.

Caution:

1. One-Way Conversion Only: This module only supports HDMI to AV signal conversion.
2. Power On/Off Sequence: For HDMI video sources with their own battery, follow the proper sequence: when powering on, connect the module power supply first, then the video source; when powering off, disconnect the video source power first, then the module power.
3. Custom Cable Options: The standard HDMI cable length is 300mm, but users can opt for a 500mm cable or request other custom lengths.

Applications:

This module is perfect for drone enthusiasts and professionals requiring high-definition video signal conversion from HDMI to AV. It is well-suited for UAV systems, multi-axis setups, and FPV drone applications where high-quality video transmission is essential for operations such as aerial photography, inspections, and surveillance.

Packing List:

• HDMI to AV Module (300mm HDMI Cable) ×1
• 1.0-8P Single-Ended Cable (150mm) ×1
• Cup Head Screw (M2*6mm) ×2

Tarot HDMI to analog audio/video conversion module, directly connected display screen, wireless display screen.
