Yunshis P8864 3D TOF Miniature Sensor Module, UART TTL 5V, 8x8/4x4 Area Array Ranging

Yunshis

$138.25 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Version P8864 Area array module P8864 Development kit

Resolution 8×8 resolution 4×4 resolution

Quantity

View full details

Overview

Yunshis P8864 is a 3D TOF Miniature Sensor module (solid-state area array ranging module / TOF LiDAR ranging sensor) designed for compact distance sensing and easy system integration. The P8864-SMD series integrates a 3D TOF (Time-of-Flight) sensor with up to 64 pixels, a microprocessor, and an optional PMU (Power Management Unit).

Key Features

Solid-state area array ranging module
Two operating resolutions: 8x8 and 4x4
UART TTL communication output
940nm VCSEL light source
Ambient light immunity: 70Klux
Eye safety: IEC60825-1 Class 1
Compact size: 18mm L x 12mm W x 4.49mm H; module weight <3g

Specifications

Parameter	8x8	4x4
Ranging Principle	TOF (Time of Flight)
Resolution	8x8	4x4
Ranging Range	0.1-1.5m @ 90% Reflectance	0.1-4m @ 90% Reflectance
Field of View (FOV)	30°	16°
Distance Accuracy	0.1-1m: 4cm; >1m: 4%	0.1-1m: 4cm; >1m: 4%
Distance Repeatability	0.1-0.5m: 1cm; >0.5m: 2%	0.1-0.5m: 1cm; >0.5m: 2%
Ambient Light Immunity	70Klux
Communication Output	UART TTL
Light Source	940nm VCSEL
Supply Voltage	5V
Power Consumption	360mW
Operating Temperature	-10~60°C
Storage Temperature	-20~80°C
Eye Safety	IEC60825-1 Class 1
Module Dimensions	18mm L x 12mm W x 4.49mm H
Module Weight	<3g

Mechanical / Connector Notes (from drawing)

Model in drawing: FS8864-SME-A40 (Unit: mm)
Overall size called out: 18.00 (L) x 12.00 (W) x 4.49 (H)
Additional dimensions shown include: 7.80, 4.80, 5.00, 2.00, 2.01, 1.49, 1.00, 0.80
Mounting holes: 2x φ1.20
Connector type: Hirose Electric Co., Ltd. HRS FH26W-15S-0.3SHW or similar
Note: The two mounting holes should connect to a heat sink or copper area on the supporting circuit board for heat dissipation; the heat sink or copper area should be N.C. (No Connection).
