12W Anti Drone Module SPECIFICATIONS
Brand Name: NoEnName_Null
Item Type: original
Origin: Mainland China
Model Number: 12w blocking
12W SWEEP SOURCE FOR WiFi/ DRONE
Only the Tansmitting Channel (TX), NO RX
Frequency:2.4GHz-2.5GHz(3 other optional)
RFOUT POWER=47dBm(12W)
IND-BOOSTER accept customizing the power you need!
No. |
Items |
Specifications |
1 |
Frequency Range |
2400-2500MHz |
2 |
Operating Voltage |
20-24V(customizable28-32V) |
3 |
Flatness |
±0.5dB |
4 |
Output Power |
41dBm |
5 |
Current |
1.0A @24V, 41dBm |
6 |
Efficiency |
50%@41dBm |
7 |
LED State |
Red |
8 |
Operating Temperature |
-30℃~85℃ |
9 |
Storage Temperature |
-40℃~150℃ |
10 |
Operating Humidity |
<95%RH |
11 |
RF PORT |
Output: SMA-F |
12 |
Power Socket |
Feed-through Cpacitor |
13 |
Shell Material |
Aluminum |
14 |
Shell Size |
80*46*21mm |
15 |
Net Weight |
0.13Kg |
1 24V /4.5A power supply.
2 Heat dissipation is recommended, such as adding heat sink or radiator fan.
3 Antenna should be screwed first, then plug the power adapter.
