2023 New DarwinFPV TinyAPE/TinyAPE Freestyle - 2.5 Inch 2-3S FPV Racing RC Drone w/RunCam Nano 4 1103 Motor 5.8G VTX Thumb Camera ELRS

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle - 2.5 Inch 2-3S FPV Racing RC Drone w/RunCam Nano 4 1103 Motor 5.8G VTX Thumb Camera ELRS

DarwinFPV

Regular price $196.61 USD
Regular price $275.26 USD Sale price $196.61 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

40 orders in last 90 days

Color

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

DarwinFPV TinyAPE/TinyAPE Freestyle SPECIFICATIONS

Video Capture Resolution: Other

Type: HELICOPTER

Remote Distance: 1000

Remote Control: No

Recommend Age: 12+y,18+

Package Includes: Original Box

Origin: Mainland China

Model Number: TinyAPE

Material: Carbon Fiber

Indoor/Outdoor Use: Outdoor

Features: App-Controlled

Controller Mode: MODE2

Controller Battery: 2

Control Channels: 6 Channel

Camera Mount Type: Other

Aerial Photography: Yes

Tiny Ape Freestyle is the first 2.5'' drone from Darwinfpv. In order to meet the needs of more friends and we have made multiple attempts. It comes with the Darwin ELRS2.0 F411 15A Bluejay AIO and the VTX006 which has 25-600mW output power.


Configuration:

Brand: DarwinFPV



TinyAPE
Tiny Ape Freestyle
Weight
50.3g (without batteries and paddles)
50.3g (without batteries and paddles)
Propeller
Genfan 2512 3-blade propeller
Genfan 2512 3-blade propeller
FC&ESC
F411 2S 15A FC (Built-in ELRS 2.4G receiver)
F411 2S 15A FC (Built-in ELRS 2.4G receiver)
Built-in Receiver Protocol
SPI protocol
SPI protocol
Motor
1103 8000KV Brushless Motor
1103 8000KV Brushless Motor
Camera
Run Cam Nano 4
Run Cam Nano 4
VTX
 25-600mW VTX
 25-600mW VTX
AIO Firmware
betaflight_4.3.0_BETAFPVF4SX1280
betaflight_4.3.0_BETAFPVF4SX1280
ESC Firmware
Bluejay_S_H_50_48_v0.14
Bluejay_S_H_50_48_v0.14
Recommended Battery
2S 380-450mah (Not Included)
2S 380-450mah (Not Included)

RunCam Thumb Camera

Without RunCam Thumb Camera
With RunCam Thumb Camera


Factory AIO firmware just only support ELRS_V1.0 if you want to use it with the ELRS V2.0 version TX Module and you can programming

Betaflight V4.3.0 RC1-RC3. The name of the firmware is BETAFPVF4SX1280.


Run Cam Nano 4 Camera

The Run Cam Nano 4 uses a 1/3'' CMOS sensor, 2.1mm lens and 800TVL resolution for truer colors and clearer low-light night vision.


1103 8000KV Brushless motor

1103 8000KV Brushless motor is only 3.7g and it’s power and thrust are surprising, and the flight time is achieved? Minutes. We have notice: the motor only supports 2S batteries, and if it is connected to 3S to push the throttle too much the motor will be permanently damaged .



380mah(3S)
450mah(2S)
Landing voltage
9.75V
6.5V
VTX Power
400mW
400mW
Hover Time
8.25min 8.18min


VTX
VTX006 has 25-600mW output power and can provide stable images and powerful transmission. You can choose the perfect output

power according to you FPV requirements. ( The default setting of the output power for Tiny Ape is 400mW)


Red light flashes frequency
Power
1 25mW
2 200mW
3 400mW
4 600mW


Flight Control(FC)
This is an updated version of Darwin AIO. We integrated the ELRS receiver on the FC to make it easier to apply to mini drones. The ESC

adopts Bluejay firmware, compatible with 1-3S Lipo input, 15A continuous current and 17A peak current. FC provides 2 sets of Uarts

 interfaces, and also provides various external device interfaces such as SBUS, Softserial, CTR, BUZZ, RGB, etc., which perfectly solves the

problemof insufficient number of F411 Uarts.


The built-in receiver is an SPI protocol receiver, so you need to select SPI receiver support (SPI RX support) in the betaflight configurator.

Under normal circumstances, the checkbox on the betaflight configurator receiver is empty. If the betaflight configurator used is 10.8.0 and above, the checkbox should select "EXPRESSLRS". As shown below.

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, this drone is an excellent choice for both new and experienced pilots looking to explore the exciting world




Package Included:

1* DarwinFPV TinyAPE/ DarwinFPV TinyAPE Freestyle

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, The 2023 New DarwinFPV TinyAPE/Tiny APE Freestyle

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, comes with the Darwin ELRS2.0 F411 15A Bluejay AIO and

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, the RunCam Nano 4 camera captures sharp and vibrant video footage during freestyle flights

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, The 2023 New DarwinFPV TinyAPE/Tiny APE Freestyle

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, Beginner-Friendly Features: The drone offers multiple flight modes, including stabilized modes

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, 5.8G VTX ensures reliable video transmission to compatible FPV goggles

2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, this drone is perfect for both indoor and outdoor flying . with its compact size, powerful components

Related Article:

(If there is any information error in the article, the product description shall be the standard.)

Title: Unleash Your Freestyle Skills with the 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle

Introduction:
The 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle is an impressive 2.5-inch FPV racing drone designed to deliver an exhilarating freestyle flying experience. With its compact size, powerful components, and advanced features, this drone is perfect for both indoor and outdoor flying. In this comprehensive review, we will explore the composition, functions, parameters, advantages, related competing products, how to choose, DIY assembly tutorials, operation tutorials, and frequently asked questions (FAQ) related to the 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle.

Composition and Functions:
The 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle consists of the following components:

1. Frame: The drone features a durable and lightweight frame designed to withstand crashes and impacts. The compact size allows for agile and responsive flight maneuvers.

2. Flight Controller: Equipped with a reliable flight controller, the TinyAPE/TinyAPE Freestyle offers stability and precision control during flight. It supports various flight modes, allowing both beginners and experienced pilots to enjoy the drone's capabilities.

3. Motors: The 1103 motors provide ample power and thrust for agile freestyle flying. They offer a balance between speed and efficiency, ensuring an enjoyable flying experience.

4. Camera: The drone is equipped with the RunCam Nano 4 camera, which captures high-quality video footage and provides clear FPV transmission. It offers an immersive view for precise control and an exciting freestyle experience.

5. Video Transmitter (VTX): The integrated 5.8G VTX ensures reliable video transmission to compatible FPV goggles or monitors, allowing for real-time FPV flying.

Advantages:
1. Compact and Lightweight: The TinyAPE/TinyAPE Freestyle's small size and lightweight design make it highly maneuverable, enabling pilots to perform acrobatic freestyle tricks and navigate tight spaces.

2. Durable Construction: The drone's sturdy frame and quality components are built to withstand crashes and impacts, ensuring durability and longevity.

3. High-Quality Camera: The RunCam Nano 4 camera captures sharp and vibrant video footage, providing an immersive FPV experience during freestyle flights.

4. Beginner-Friendly Features: The drone offers multiple flight modes, including stabilized modes, which are ideal for beginners who are learning to fly FPV drones.

Related Competing Products:
- Diatone GTB229 Cube
- BetaFPV Beta85X V2
- GEPRC CineEye 79mm

How to Choose:
When selecting the 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle, consider the following factors:

1. Flying Environment: Determine whether you intend to fly primarily indoors or outdoors. The TinyAPE/TinyAPE Freestyle's compact size makes it suitable for both environments.

2. Skill Level: The drone is suitable for beginners and experienced pilots alike. Beginners can benefit from the drone's stability and beginner-friendly flight modes, while experienced pilots can push its limits with advanced freestyle maneuvers.

DIY Tutorials:
The TinyAPE/TinyAPE Freestyle comes as a partially assembled drone. Follow the manufacturer's instructions to complete the assembly, which typically involves attaching the propellers, installing the camera, and configuring the flight controller.

Operation Tutorials:
1. Pre-flight Checks: Before each flight, ensure that the battery is fully charged, propellers are securely attached, and all connections are properly made. Conduct a thorough inspection of the drone for any physical damage.

2. Power On: Insert a fully charged battery into the drone, ensuring proper polarity. Power on the drone and the remote controller, and confirm that the

video transmission is clear.

FAQ:
1. What is the recommended battery for the TinyAPE/TinyAPE Freestyle?
The TinyAPE/TinyAPE Freestyle is compatible with 2S and 3S LiPo batteries. The specific battery capacity will depend on your flying style and desired flight time.

2. Can I upgrade the components of the TinyAPE/TinyAPE Freestyle?
Yes, the TinyAPE/TinyAPE Freestyle allows for component upgrades, including motors, flight controllers, and cameras. Ensure compatibility and follow proper installation procedures.

Conclusion:
The 2023 New DarwinFPV TinyAPE/TinyAPE Freestyle offers a thrilling freestyle flying experience in a compact and durable package. With its powerful motors, high-quality camera, and beginner-friendly features, this drone is an excellent choice for both new and experienced pilots looking to explore the exciting world of freestyle flying. Choose the TinyAPE/TinyAPE Freestyle to unleash your creativity, perform jaw-dropping maneuvers, and take your FPV skills to new heights.
