Caddx Turbo S1 600TVL Camer SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Other

Unit Type: piece

Tool Supplies: Other

Technical parameters: Value 10

Remote Control Peripherals/Devices: Other

Recommend Age: 18+,12+y

RC Parts & Accs: Other

Package Weight: 0.02kg (0.04lb.)

Package Size: 5cm x 5cm x 5cm (1.97in x 1.97in x 1.97in)

Origin: Mainland China

Model Number: Caddx Turbo S1 600TVL Camera

Material: Composite Material

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Helicopters

CADDX.US Turbo S1 1/3 CCD 600TVL IR Blocked FPV Camera Yellow/Green NTSC/PAL DC 5V-40V Wide Voltage

Description

Model	Turbo S1
Image Sensor	1/3" CCD Sensor
Horizontal Resolution	600 TVL
TV System	NTSC/PAL
Synchronization	Internal

 Ratio                                                4:3

Electronic Shutter	PAL: 1/50~100,000; NTSC: 1/60~100,000
S/N Ratio	>60dB (AGC OFF)
Video Output	CVBS
Lens	2.5mm ,FOV 130°
Lens Screw Diameter	M10
Min. Illumination	0.01Lux@ F1.2
Auto Gain Control	YES
BLC	YES
FLY OSD	Voltage/time/horizontal line/title
Camera OSD	YES
WDR	D-WDR
DNR	2 DNR
Day/Night	Auto/Color/B&W
Connector	Molex PicoBlade 1.25mm 4P
Wide Power Input	DC 5-40V
Work Temperature	-20°~+60°
Work Humidity	20%~80%
Dimension	22mm*22mm*27mm
Weight	12g (N.W.)/ (G.W.)



Package Included

1 x Caddx Turbo S1 600TVL Camera

1 x 5D-OSD Menu Board

1 x ABS+PV Bracket

1 x Aluminum Bracket

1 x 4pin FPV silicone cable (extend into a 2pin joint for OSD board and a 3pin joint for FPV)

1 x Screws set

1 x Manual

Compare with other camera:
Night(Caddx on Left ):


Daytime (Caddx on right ):



'
