• EaglePower X10 KV115 12S 15KG Thrust Brushless Motor for Agriculture Drone
  • EaglePower X10 KV115 12S 15KG Thrust Brushless Motor for Agriculture Drone
  • EaglePower X10 KV115 12S 15KG Thrust Brushless Motor for Agriculture Drone
  • EaglePower X10 KV115 is a high-performance brushless motor for RC drones, offering efficient power output.
1 4

EaglePower X10 KV115 12S-14S 15KG Thrust Brushless Motor for Agriculture Drone

EaglePower X10 KV115 12S-14S 15KG Thrust Brushless Motor for Agriculture Drone

EaglePower

$199.00 USD
$199.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Type
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
View full details

Overview

The EaglePower X10 KV115 is a high-performance brushless motor engineered for agriculture and industrial drones requiring heavy-lift capability. With a maximum thrust of 14.9kg when paired with a 12S LiPo battery and UP3212 propeller, this motor delivers efficient, reliable power for demanding aerial applications. Its low internal resistance and optimized mounting structure make it ideal for multi-rotor platforms.

Specifications

Parameter Value
Model X10 KV115
Configuration (N / P) 36N42P
Motor Size (mm) Φ108 × 32.9 mm
Weight 560 g
Recommended Battery 12S – 14S LiPo
No-load Current 1.4A @ 24V
Max Continuous Current 56.5A (with 12S LiPo + UP3212 propeller)
Max Continuous Power 2738W (with 12S LiPo + UP3212 propeller)
Max Thrust 14900 g (with 12S LiPo + UP3212 propeller)
Internal Resistance 54.5 mΩ
Stator Mounting Hole 4×M4, Φ40 mm
Rotor Mounting Hole 4×M3, Φ31 mm
Spindle Diameter 15 mm

Load Test Parameters (with 12S LiPo & UP3212 Propeller)

Pulling Force (g) Current (A) RPM Power (W) Efficiency (g/W) Torque (N·m)
1520 1.85 1120 89.54 16.9757 0.7635
3030 4.9 1560 237.16 12.7762 1.4518
4530 8.8 1906 425.92 10.6358 2.1341
6050 13.45 2350 650.98 9.2937 2.6455
7560 19.15 2505 960.82 7.8672 3.9512
9030 26.25 2755 1270.5 7.1074 4.4041
10750 33.52 2980 1622.368 6.6261 5.2963
12300 43.3 3250 2029.45 6.0606 6.2727
13800 50.32 3468 2435.488 5.6662 6.7604
14900 56.58 3504 2738.472 5.4410 7.4636

Note: Recommended takeoff weight is 5500–6500g per motor. All values measured at 100% throttle.

Applications

The EaglePower X10 motor is ideal for:

  • Agriculture drones (crop spraying, seeding)

  • Heavy-lift multi-rotor UAVs

  • Aerial logistics and mapping

  • Industrial drone platforms

Details

EaglePower X10 Brushless Motor, E-POWER X10 KV115 motor features 36N42P, weighs 560g, max thrust 14900g, max power 2738W, and has 4xM4 stator and 4xM3 rotor mounting holes.

E-POWER X10 KV115 motor specifications: 36N42P, 108x32.9 mm size, 560g weight, 12S-14S battery, 1.4A/24V no-load current, 56.5A max continuous current, 2738W max power, 14900g max thrust, 54.5mΩ internal resistance, 4xM4 stator mounting holes, 4xM3 rotor mounting holes, 15mm spindle diameter.

EaglePower X10 Brushless Motor, X10 test parameters with KV110 motor, 12S battery, UP3212 propeller. Data includes force, current, RPM, power, efficiency, torque for 5500-6500g weights. Efficiency peaks at lower forces.

X10 test parameters include load tests with a KV110 motor, 12S lithium battery, and UP3212 propeller. Data covers pulling force, current, RPM, power, efficiency, torque, and notes for various weights from 5500 to 6500g. Results show increasing values as pulling force rises, with maximum efficiency at lower forces.

EaglePower X10 Brushless Motor, Specifications for X10 KV115 model, including motor size, weight, recommended battery, and performance data.
