Foxeer 5.8G 1.8W VTX Overview
The Foxeer 5.8G Reaper Extreme 1.8W 72CH VTX is a high-performance video transmitter designed for FPV enthusiasts who require powerful video transmission with adjustable power settings. Capable of delivering up to 1.8W of output power, this VTX ensures long-range, clear video feed across 72 channels, providing flexibility and reducing interference. The compact design, coupled with Tramp protocol support, makes it ideal for seamless integration with your FPV system. The VTX also supports PIT mode for safe, low-power transmission during race setup or indoor environments.
Foxeer 5.8G 1.8W VTX Features
- Adjustable Power Levels: The VTX offers 25mW, 200mW, 500mW, 1W, and 1.8W power levels, with a corresponding red light flash (1-5 times) to indicate the power setting, allowing pilots to optimize signal strength for different flying scenarios.
- 72 Channels: Covers a wide range of frequencies to provide flexibility and minimize interference.
- PIT Mode: Double-click the "KEY" button to enter PIT mode, which reduces transmission power to a safe level for race setup or indoor flying.
- Tramp Protocol Support: When connected via the Tramp cable, the VTX’s button is disabled, and frequency and power adjustments are managed by the flight controller.
- Compact and Lightweight: The VTX is compact at 36x27.5x8mm and weighs only 13g, making it easy to install in most FPV drone builds.
- Low Power Consumption: Consumes 850mA at 10V/1.8W, ensuring efficient power usage without compromising video transmission quality.
Foxeer 5.8G 1.8W VTX Specifications
Name | Reaper Extreme 1.8W |
Input Voltage | 9~36V |
Output Voltage | 5V |
Channels | 72CH |
Power | 25mW/200mW/500mW/1W/1.8W, red light flash 1/2/3/4/5 times correspondingly |
Pit | Double click to enter |
Weight | 13g |
Mounting Hole | 20*20mm M2 2.8mm depth |
Size | 36*27.5*8mm |
Consumption | 850ma;10V/1.8W |
Package Includes | 1 x VTx; 1 x silicon cable; |
Frequency Table
Band | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
Band A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
Band B | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 |
Band E | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 |
Band F | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
Band R | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Band H | 5653 | 5693 | 5733 | 5773 | 5813 | 5853 | 5893 | 5933 |
Band L | 5333 | 5373 | 5413 | 5453 | 5493 | 5533 | 5573 | 5613 |
Band U | 5325 | 5348 | 5366 | 5384 | 5402 | 5420 | 5438 | 5456 |
Band O | 5474 | 5492 | 5510 | 5528 | 5546 | 5564 | 5582 | 5600 |
Foxeer Reaper Extreme VTX Camera Module, 5.8GHz, 72CH, 1.8W Output Power, MMCX Video Out, RoHS Compliant, Made in China.
