Foxeer Black Hornet 2809 1300KV FPV Motor

Overview

The Foxeer Black Hornet 2809 1300KV motor is specifically engineered for high-performance FPV drone pilots who demand a powerful, durable, and efficient motor. With its 1300KV rating, this motor is perfect for 4S to 6S LiPo battery setups, delivering consistent power while maintaining efficiency. The 28mm stator diameter and 9mm stator length are optimized for strong thrust and smooth flight, while the 4mm hollow titanium shaft reduces weight without compromising structural strength. This motor is designed to endure high temperatures with its military-grade 260°C radiation-resistant winding, ensuring optimal performance in demanding environments.

Key Features

1. 1300KV Rating: Delivers strong thrust and efficient power, perfect for both racing and freestyle FPV applications.
2. N52H High-Quality Magnets: Equipped with N52H magnets that ensure powerful magnetic fields and fast response times during intense flight.
3. Military-Grade High-Temperature Resistance: Built with 260°C radiation-resistant winding, this motor can withstand extreme conditions, ensuring durability and efficiency.
4. Ultra-Light Hollow Titanium Shaft: The hollow titanium shaft significantly reduces motor weight while maintaining its structural integrity, improving flight performance.
5. Optimized for 4S to 6S LiPo: This motor offers wide battery compatibility, making it adaptable for various drone setups.

Specifications

Foxeer Black Hornet 2809 1300KV FPV Motor: The ultra-light EMI-hollow titanium shaft effectively reduces weight while ensuring strength. The motor features NSZH high-quality magnets, surging power, and a high-temperature wingding design. It also has a high-quality stator with single-crystal oxygen-free copper wire winding for high efficiency. Technical Data: Kv: 1300 Configuration: 12N14P Stator Diameter: 28mm Stator Length: 9mm Shaft Diameter (Hollow): 4mm Motor Dimensions (Dia. x Len.): 34.3 x 21.3mm Weight: 59g Wire Length: ? Idle Current: 0.65A (10V @ 1Ohm) No. of Cells (Lipo): 4-6S Max Continuous Power: 1433W (5S) Internal Resistance: 56mΩ Max Current (5S): 59.7A Max Efficiency Current (4-9A): 85%
