GEPRC EF10 5.8G 1.6W Long Range 10inch FPV SPECIFICATIONS
Brand Name: GEPRC
Remote Distance: 2000 meters
Remote Control: Yes
Package Includes: Original Box
Package Includes: Operating Instructions
Package Includes: Camera
Anti-wind Ability: NO
Video Capture Resolution: 1080p FHD
Video Capture Resolution: 2K QHD
Video Capture Resolution: 4K UHD
Controller Battery: Not include
Takeoff Weight: 100g
Aerial Photography: Yes
Control Channels: 8 CHANNELS
Material: Metal
Material: plastic
Material: Carbon Fiber
Flight Time: <5
Origin: Mainland China
Controller Mode: MODE1
Controller Mode: MODE2
Recommend Age: 14+y
Transit Time (Days): 1KM
Drone Weight: 984g
Dimensions: 10 inch
Motor: Brushless Motor
Plugs Type: XT90
Type: HELICOPTER
State of Assembly: Ready-to-Go
Features: App-Controlled
Features: FPV Capable
Features: Integrated Camera
Features: Other
Indoor/Outdoor Use: Indoor-Outdoor
Charging Voltage: 14.8V
Charging Time: 30 minutes
Camera Mount Type: Fixed Camera Mount
Camera Mount Type: Other
Warning: Minors please use under the supervision of an adult
Certification: CE
CE: Certificate
Model Number: GEPRC EF10 5.8G 1.6W Long Range FPV
Power Source: Electric
Operator Skill Level: Beginner
Operator Skill Level: Intermediate
Operator Skill Level: expert
Feature
-
High-power VTX ensures signal stability and reliability
-
Equipped with EM3115 KV900 motors, using 10-inch propellers, maximum load 4kg
-
Using TAKER BLS 80A ESC high-performance hardware, 48 high-power MOS for more stable output
-
GEP-F405-BT flight controller, supports mobile phone Bluetooth parameter adjustment
-
Upgraded high-strength 7mm thick arms and wide X-shape structure ensure overall flight stability
-
Newly designed fixed power plug makes powering on more convenient
Specifications
-
Model: GEPRC EF10 Long Range FPV
-
Frame: GEP-EF10
-
Wheelbase: 430mm
-
Top plate thickness: 2mm
-
Medium plate thickness: 3mm
-
Bottom plate thickness: 3mm
-
Side panel thickness: 2.5mm
-
Arm thickness: 7mm
-
FC: GEP-F405-BT
-
ESC: TAKER BLS 80A 4IN1
-
MCU: STM32F405RGT6
-
Gyro: ICM-42688-P
-
VTX: RAD VTX 5.8G 2.5W / RAD VTX 5.8G 1.6W / MATEN 1.2G 2W VTX
-
Camera: Caddx Ratel2
-
Antenna: Momoda 5.8G RHCP SMA interface
-
Motor: EM3115 KV900
-
Propeller: HQProp 1050-3
-
Connector:XT90
-
Weight: 969g
Includes
1 x GEPRC EF10
4 x HQProp 1050-3
2 x Battery anti-slip pads
1 x Spare screw pack
1 x L-shaped screwdriver 1.5mm
1 x L-shaped screwdriver 2.0mm
1 x M5 wrench
