Features

1.  The appearance is matte black with bright edges, which is exquisite and beautiful.

2.  Use high-quality bearings with high precision and durability.

3. Three-hole screw base, light weight.

4.  Suitable for 1.6-inch-2-inch lightweight models.

Specifications

• Model: SPEEDX2 1102 10000KV Motor

• Max Watt: 59.6W

• Peak current: 7.45A

• Interphase resistance: 251mΩ

• Magnet: N52H

• Bearing type: NSK/NMB

• Configuration: 9N12P

• Dimension: φ13.8mmx12.7mm

• Shaft Diameter: φ1.5mm

• Shaft Protruding Length: 3.5mm

• Mounting holes: 3-φ6.6mm

• Lead: 35mm/28AWG

• ESC:12A

• Input Volts: 8.4V（2S LiPo)

• Winding: multi strand copper winding

• Weight: 2.83g (included wire)

• Suitable for:1.6 inch -2 inch lightweight models

Includes

1 x SPEEDX2 1102 motor

6 x M1.4*3 Round torx screw

Specifications GEPRC SPEEDX2 1102 KV 1OOOOKV Max Watt 59.6W Peak current 7.45A Interphase resistance 251mn Propeller HQ DTSI-4B Magnet N52H Bearing type NSK/NMB Configuration IN1ZP Dimension 613.8mmx12.Zmm Shaft Diameter $1.SMM Shaft Protruding Length 3.5mm Mounting holes 3-06.6mm Lead 35mm/28AWG ESC 12A Input
