GEPRC SPEEDX2 1102 10000KV 2S Brushless FPV Motor for 1.6 to 2 Inch Racing Drones

Overview

The GEPRC SPEEDX2 1102 10000KV Brushless FPV Motor is designed for 1.6 to 2 inch lightweight racing drones, offering smooth, controlled power output on a 2S LiPo setup. Featuring a matte black finish with polished accents, this motor combines sleek aesthetics with functional performance.

Built with a 9N12P stator, N52H magnets, and NSK/NMB bearings, the SPEEDX2 1102 delivers high efficiency, excellent thermal stability, and low vibration. At only 2.83 grams including wire, it’s an ideal choice for tight indoor tracks or agile freestyle builds.

Key Features

• 10000KV micro motor for 2S setups

• Compatible with 1.6 to 2 inch drone builds

• 1.5mm shaft with 3.5mm protrusion, T-mount ready

• CNC matte black bell with bright edge detailing

• N52H magnets and high-precision NSK/NMB bearings

• Lightweight at 2.83g including 35mm silicone wire

• Supports 12A ESCs

Specifications

Package Includes

• 1 × GEPRC SPEEDX2 1102 10000KV Brushless FPV Motor

• 6 × M1.4 × 3mm Torx Mounting Screws

Specifications GEPRC SPEEDX2 1102 KV 1OOOOKV Max Watt 59.6W Peak current 7.45A Interphase resistance 251mn Propeller HQ DTSI-4B Magnet N52H Bearing type NSK/NMB Configuration IN1ZP Dimension 613.8mmx12.Zmm Shaft Diameter $1.SMM Shaft Protruding Length 3.5mm Mounting holes 3-06.6mm Lead 35mm/28AWG ESC 12A Input
