GEPRC SPEEDX2 2809 V1.1 Motor 1450KV/1280KV, 5mm Shaft, 19x19mm Mount, 25.2V (6S)

GEPRC SPEEDX2 2809 V1.1 Motor 1450KV/1280KV, 5mm Shaft, 19x19mm Mount, 25.2V (6S)

GEPRC

$49.00 USD
$49.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
KV
  • PayPal
  • Visa
  • Mastercard
  • American Express
  • JCB
  • Discover
  • Diners Club
  • Google Pay
  • Apple Pay
View full details

Overview

The GEPRC SPEEDX2 2809 V1.1 Motor (1450KV / 1280KV options) is designed for 7–8 inch long-range FPV builds. It uses a stator with 0.2mm Kawasaki silicon steel for efficient magnetic flow and N52H magnets for improved high-temperature resistance. The motor uses a 19mm x 19mm mounting pattern.

Key Features

  • New Version, Superior Performance
  • SPEEDX2 Series Simple Appearance Design; unique appearance, science fiction design elements
  • Integrated Outer Rotor: using 7075 aviation aluminum alloy, high-precision CNC integrated
  • Exquisite Color Matching: overall dark appearance with red edge
  • High-strength motor structure: rotor edge structure conforms to the load-bearing mechanical design and has strong impact resistance
  • Efficient Magnetic Circuit Scheme: high-quality N52H magnetic steel is used to prevent high temperature demagnetization
  • N52H arc-shaped magnets: strong magnetism, stable power output and high efficiency
  • Energy-saving stator: low heating, improving work efficiency and endurance; low energy consumption
  • Damping O-ring: reducing motor vibration and improving bearing lifetime
  • 5mm output shaft carburizing heat treatment: high strength and good stability
  • Reinforced base: high structural strength

Specifications

Series SPEEDX2
Model GEPRC SPEEDX2 2809 V1.1 Motor
KV options 1450KV / 1280KV
Magnet N52H
Rotor material 7075 (7075-T6 stated)
Stator diameter 28mm
Stator height 9mm
Bearing type NSK/NMB
Configuration 12N14P
Dimensions Dia 34.2mm * 36.7mm
Overall height (drawing) 36.7mm +/-0.5
Body height (drawing) 21.7mm +/-0.3
Motor diameter tolerance (drawing) Dia 34.2mm +/-0.1
Shaft diameter 5mm (drawing: Dia 5 -0.02/-0.06)
Shaft protruding length 15mm (drawing: 15 +/-0.2)
Propeller 7–8 Inch
Mounting holes 19mm x 19mm (M3 stated)
Lead 18AWG 250mm (spec table); drawing shows 260mm (260 +/-5)
Input volts 25.2V (6S Lipo)
Recommended ESC 50A–70A
Winding Single strand copper winding
Color Reddish black
Weight (included wire) 60 +/-1.5g
Compatible models 7–7.5 inch long-range FPV drones / 7–7.5 inch X8 builds

Electrical & Output (by KV)

Parameter 1450KV 1280KV
Max Watt 1486.5W <=1455.2W
Peak current 60.88A 59.06A
Interphase resistance 50.8mohm +/-5% 60.17mohm +/-5%

Performance Data (Motor Data Sheet)

SPEEDX2 2809 1450KV

Prop (inch) Voltage (V) Throttle (%) Current (A) Thrust (G) Power (W) Efficiency (G/W) Temperature (°C)
7*4*3 25 50% 14.22 1035 354.3 2.9 126°C
60% 20.49 1393 508.7 2.7
70% 30.46 1752 753.1 2.3
80% 38.21 2059 941.4 2.2
90% 49.81 2345 1221.8 1.9
100% 60.88 2592 1486.5 1.7
7.5*3.7*3 25 50% 12.85 986 320.3 3.1 103°C
60% 19.51 1387 484.8 2.9
70% 28.01 1748 693.3 2.5
80% 37.64 1882 927.5 2
90% 47.99 2185 1178.2 1.9
100% 58.3 2383 1425.1 1.7
7.5*3*3 25 50% 11.16 982 278.3 3.5 117°C
60% 17.96 1365 446.5 2.7
70% 25.69 1782 636.3 2.8
80% 34.5 2144 851.4 2.5
90% 44.26 2493 1087.5 2.3
100% 55.71 2795 1362.9 2.1

SPEEDX2 2809-1280KV

Prop (inch) Throttle (%) Voltage (V) Current (A) Thrust (G) Power (W) Efficiency (G/W) Temperature (°C)
7*4*3 50% 24.91 11.35 819 285.5 2.87 86°C
60% 24.83 16.7 1152 419 2.75
70% 24.72 23.19 1512 579.4 2.61
80% 24.64 31.97 1841 796.2 2.31
90% 24.53 42.26 2146 1048.1 2.05
100% 24.42 53.66 2482 1324.5 1.87
7.5*3.7*3 50% 24.92 8.84 846 222.5 3.8 98°C
60% 24.85 13.47 1201 338.4 3.55
70% 24.75 19.3 1525 483.6 3.15
80% 24.66 26.5 1913 661.6 2.89
90% 24.55 34.98 2257 870.4 2.59
100% 24.44 44.37 2587 1099.8 2.35
8*4*3 50% 24.94 11.7 1050 294.3 3.57 122°C
60% 24.86 18.63 1469 466.9 3.15
70% 24.77 26.25 1865 655.3 2.85
80% 24.68 37.48 2234 931.9 2.4
90% 24.57 46.76 2557 1157.9 2.21
100% 24.46 59.06 2883 1455.2 1.98

Whats Included

  • 1 x GEPRC SPEEDX2 2809 Motor (1280KV or 1450KV, depending on selected option)
  • Round head M3*9 screws (4PCS)
  • M5 flange nut (1PCS)

For order support and after-sales questions, contact support@rcdrone.top or visit https://rcdrone.top/.

Applications

  • 7–8 inch propeller FPV builds
  • 7–7.5 inch long-range FPV drones
  • 7–7.5 inch X8 builds
