GEPRC TAKER F722 BLS 100A 8S Stack – F722 FC & 100A 4in1 ESC for 8S FPV Drone, DJI Plug, 12V/5V BEC

The GEPRC TAKER F722 BLS 100A 8S Stack is a powerful and reliable FPV flight stack, designed for high-performance 8S racing and freestyle drones. Featuring the STM32F722 MCU and ICM42688-P gyroscope, it ensures ultra-smooth flight control. With direct DJI Air Unit compatibility, dual BEC outputs (12V@3A & 5V@3A), and onboard 16MB blackbox, it's built for pro-level builds. The 100A 4in1 ESC supports up to 8S LiPo with DShot150/300/600 protocols and delivers consistent power for demanding aerial maneuvers.

Key Features

• High-performance STM32F722 MCU with latest ICM42688-P gyro

• 16MB onboard black box for flight log recording

• Integrated LC filter for clean video and power signals

• Type-C USB for easy configuration

• Direct DJI Air Unit plug – no soldering required

• Dual BEC outputs: 12V@3A + 5V@3A

• Supports 8S LiPo input and up to 8 motors

• Shock-absorbing silicone grommets ensure stable IMU performance

• Simple installation with 30.5×30.5mm mounting pattern

• TAKER H100 100A ESC with burst up to 105A and DShot600 support

Specifications

TAKER F722 8S Flight Controller

• MCU: STM32F722

• IMU: ICM42688-P (SPI)

• Black Box: 16MB onboard

• OSD: Betaflight OSD with AT7456E chip

• USB Port: Type-C

• Air Unit Port: DJI Plug Supported

• BEC Output: 5V@3A, 12V@3A

• Barometer: Supported

• Input Voltage: 3S–8S LiPo

• UARTs: 6

• Power Filter: Integrated LC Filter

• Mounting Pattern: 30.5×30.5mm (φ4mm holes, convert to φ3mm via silicone grommets)

• Size: 38.5×38.5mm

• Weight: 8.1g

• Firmware Target: TAKERF722SE

TAKER H100_8S_BLS 100A 4in1 ESC

• Input Voltage: 3S–8S LiPo

• Continuous Current: 100A

• Burst Current: 105A (5s)

• Ammeter: Supported (calibration value: 200)

• Protocol Support: DShot150 / 300 / 600

• Mounting Pattern: 30.5×30.5mm (φ4mm holes, convert to φ3mm with grommets)

• Dimensions: 56.3 × 61.1mm

• Weight: 28.8g

• Firmware Target: B_X_30

What's Included

• 1 × F722 Flight Controller

• 1 × 100A 4IN1 ESC

• 1 × Capacitor

• 1 × O3 3-in-1 Connection Cable

• 2 × FC Adapter Cables

• 1 × SH1.0 4-Pin Silicone Cable

• 1 × Camera Connection Cable

• 1 × VTX Connection Cable

• 1 × XT90 Power Cable

• 4 × M3×30 Screws

• 4 × M3×25 Screws

• 8 × Nylon Nuts

• 12 × Silicone Anti-Shake Pads

Details

GEPRC Taker F722 Blaster 100A 8S Stack Flight Controller with 6 Axis Gyro and Accelerometer

TAKER F722 8S Flight Controller features a STM32F722 MCU, ICM42688-P IMU with SPI connection, and supports DJI Air Unit connection. It has an onboard USB interface via Type-C, and includes a barometer for altitude measurement. The flight controller also comes with a BetaFlight OSD using AT7456E chip and dual BEC (SV@3A, 12V@3A). Its dimensions are 38.5x38.5mm to 30.5x30.5mm, with a weight of 8.1g. The ESC has an input range of 3-8S LiPo voltage and supports calibration.

The Feature uses the mainstream STM32F72Z chip. Equipped with the latest 42688-P gyroscope and onboard black box storage. Integrated LC and upgraded Type-C USB interface allow for direct plug-in to DJI Air Unit. Supports 8S Lipo batteries and 8 motors with dual independent BECs: 12V at 3A and 5V at 3A. A simple and efficient installation method features shock absorbers for stable gyroscope performance, paired with the TAKER H1000_8S_BLS ESC for a smooth flying experience.

Get the product display for a discounted price of 48% off duo, available for sale today.

Compact power supply with 2.0A output and 4-pin connector suitable for LED lighting applications.

Product List: Includes FC board, ESC board, capacitor, 3-in-1 connection cable, 2 FC adapter cables, SH1.O silicone cable, camera and VTX connection cables, XT90 power cable, M3 screws (30mm and 25mm), nylon nuts, and silicone anti-shake pads.
