Hobbymate GTS V2 2305 1800KV/2500KV 3-6S Brushless Motor for 5-Inch FPV Racing Drone
Hobbymate GTS V2 2305 1800KV/2500KV 3-6S Brushless Motor for 5-Inch FPV Racing Drone
Hobbymate
Couldn't load pickup availability
Overview
The Hobbymate GTS V2 2305 Brushless Motor is designed for high-performance FPV racing and freestyle drones. Available in two KV options — 1800KV for 6S power setups and 2500KV for 3–5S builds — this motor delivers a great balance of power, efficiency, and durability. With a hollow 4mm shaft, 12N14P configuration, and a lightweight 30g design, it ensures responsive throttle and smooth flight characteristics.
Specifications
| Parameter | Value |
|---|---|
| KV Rating | 1800KV / 2500KV |
| Stator Size | 23mm (Diameter) x 5mm (Length) |
| Configuration | 12N14P |
| Shaft Diameter | 4mm (Hollow Shaft) |
| Motor Dimensions | 29 x 29.25 mm |
| Weight | 30g (including 30mm wires) |
| Idle Current @10V | 1.9A |
| Input Voltage | 3–5S (2500KV), 6S (1800KV) |
| Max Continuous Power | 950W (180s) |
| Max Current (30s) | 45A |
| Internal Resistance | 45mΩ |
| Max Efficiency Current | >85% @ 3–6A |
Key Features
-
Two KV options tailored for both racing (2500KV) and long-range or cinematic flying (1800KV)
-
High-efficiency motor with 85%+ performance in optimal current range
-
Durable hollow 4mm shaft design for reduced weight and better impact resistance
-
Ideal for 5-inch FPV drones looking for powerful, efficient propulsion
2500Kv Test Data:
1800Kv Test Data:
Hobbymate GTS V2 FPV Motor performance data includes various props, voltages, throttle settings, load currents, pull force, power output, efficiency, and temperature under full throttle for 15 seconds.
