Hobbywing X9 Power System - 9616 110KV 12-14S with ESC+Propeller+Motor ComBo for 10L16L/22L multirotor Agriculture Drone

Hobbywing X9 Power System - 9616 110KV 12-14S with ESC+Propeller+Motor ComBo for 10L16L/22L multirotor Agriculture Drone

Hobbywing

$233.29 USD
$326.61 USD $233.29 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

17 orders in last 90 days

Color
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

Hobbywing X9 Power System SPECIFICATIONS

Wheelbase: Screws

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: power

Tool Supplies: Assembled class

Technical parameters: Value 2

Size: x9

Remote Control Peripherals/Devices: Motor

Recommend Age: 12+y

RC Parts & Accs: Engines

Quantity: 1 pcs

Origin: Mainland China

Model Number: X9

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Airplanes


Hobbywing X9: Suitable for 4-Axis 16L / 6-Axis 25L Agriculture Drone;

Hobbywing X9-Plus: Suitable for 4-Axis 20L / 6-Axis 30L Agriculture Drone;


Dear. There are two versions of this Hobbywing X9 power set. The voltage of the new version is 12-14S. The old version is 6-12S. The new version and the old version cannot be used together. Please pay attention to the distinction. Thank you



Specifications:
Technical Parameters
Maximum pulling force: 21.5KG/axis
Recommended battery: 12S lipo
Recommended takeoff weight (single axis): 7.0-9.5KG
Weight (including propeller) 1450g
Dimensions: 151.2x133.3mm

Motor
Stator size: 96x16mm
KV value: 110rpm/V
Internal resistance: 0.031ΩBE
Maximum current: 100A
Motor outer diameter: Φ103.5mm
Paddle clamp installation size: Φ25mm-4xM3; Φ31mm-4xM3
Bearing: imported ball bearing (waterproof)
Applicable carbon tube outer diameter: 40mm

ESC
Model: X-rotor/120A-FOC
Battery: 12-14S lipo
PWM input signal level: 3.3V/5V
Working pulse width: 1100μs-1940μs (curing, calibration is not supported)
Maximum allowable voltage: 52.2V
Maximum allowable current (continuous): 120A
Maximum allowable peak current (3 seconds): 150A
BEC: none

propeller:
Diameter / pitch: 34x11 inch
Hobbywing X9 Power System, X93jZI #Rem COMBO-XRotor Pro

Hobbywing's X9 Power System (9616-110KV) is a combo package designed specifically for multirotor agriculture drones. The kit includes an ESC, propeller, and motor that can support 10-22L aircraft. It features a 12S LiPo battery with a capacity range of 6-12S, as well as a PWM controller with a frequency range of 93-158F. Other specifications include a weight of approximately 23kg, a thrust rating of 1940ps, and a voltage range of 2.22V. The motor has a current rating of 120A and a power output of 96*16A. Additional features include a propeller diameter of 11 inches, a pitch angle of 30 degrees, and a thrust-to-weight ratio of approximately 3:1.

Hobbywing X9 Power System Combo - Propulsion System for Multirotor Agriculture Drone, Includes: ESC, Motor, and Propeller (22L, suitable for 10-16L multi-rotors), powered by 12S LiPo battery or compatible with 6-12S Lipo battery, with a maximum weight capacity of 93kg.

Hobbywing X9 Power System, voltage of the new version is 12-14S.Hobbywing X9 Power System, this Hobbywing X9 power set comes in two versionsHobbywing X9 Power System, ESC Model: X-rotor/120A-FOC Battery: 12-14Hobbywing X9 Power System, voltage of the new version is 12-14S.Hobbywing X9 Power System, 362 m acs #s #0 i% ias

Hobbywing X9 Power System SPECIFICATIONS Wheelbase : ScrewsHobbywing X9 Power System, Please pay attention to the distinctionHobbywing X9 Power System, 362 m acs #s #0 i% iasHobbywing X9 Power System - 9616 110KV 12-14S withHobbywing X9 Power System, x9 9616-TTOKvO,2cC X9

Hobbywing's X9 Power System (9616) features an 11,000 KV motor with a 12-14 series brushless ESC, suitable for agricultural drones and multirotors.

Hobbywing X9 Power System, this Hobbywing X9 power set comes in two versionsHobbywing X9 Power System, ESC Model: X-rotor/120A-FOC Battery: 12-14Hobbywing X9 Power System, this Hobbywing X9 power set comes in two versionsHobbywing X9 Power System, ESC Model: X-rotor/120A-FOC Battery: 12-14Hobbywing X9 Power System, the new version and the old version cannot be used togetherHobbywing X9 Power System, 362 m acs #s #0 i% iasHobbywing X9 Power System, this Hobbywing X9 power set comes in two versionsHobbywing X9 Power System, Please pay attention to the distinction

Hobbywing X9 Power System, 362 m acs #s #0 i% iasHobbywing X9 Power System, the new version and the old version cannot be used togetherHobbywing X9 Power System, this Hobbywing X9 power set comes in two versionsHobbywing X9 Power System -

store no. 3625186 mjj u+c 1 8 cloovtzeoozozsl

Hobbywing X9 Power System, the new version and the old version cannot be used togetherHobbywing X9 Power System SPECIFICATIONS Wheelbase : ScrewsHobbywing X9 Power System - 9616 110KV 12-14S with

Hobbywing X9 Power System, this Hobbywing X9 power set comes in two versions

store no; 362 m acs #s #0 i% ias eeweight:80.7g ' n
