iFlight Chimera CX10 ECO 452mm Wheelbase 10 Inch FPV Frame Kit with 6mm Arm
iFlight Chimera CX10 ECO 452mm Wheelbase 10 Inch FPV Frame Kit with 6mm Arm
iFlight
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: IFLIGHT
Origin: Mainland China
Material: Carbon Fiber
Recommend Age: 14+y
RC Parts & Accs: Antennas
Size: 452mm 10inch
For Vehicle Type: Airplanes
Use: Vehicles & Remote Control Toys
Certification: CE
Upgrade Parts/Accessories: Frame
Remote Control Peripherals/Devices: Remote Controller
Tool Supplies: Battery
Quantity: 1 pcs
Technical parameters: Value 2
Model Number: CX10 ECO
Four-wheel Drive Attributes: Assemblage
Wheelbase: Bottom Plate
Description
-
It's proud to announce the release of the CX10 ECo Frames, CX10 is a 10" size quadcopter, fit for the DJI O3 Air Unit system and Caddx Digital FPV system on it.
Specifications
-
Product Name: CX10 ECO 10 inch FPV frame Kit
-
Wheelbase: 452mm
-
Frame Dimension: L338*W299*H34mm
-
Arm Thickness: 6mm
-
Bottom Plate Thickness: 3mm
-
Top Plate Thickness: 2mm
-
Upper Plate Thickness: 3mm
-
Max Flight Stack Height: 21mm
-
Max VTX Height: 30mm
-
Flight Stack Mounting: 30.5*30.5mm φ3mm
-
VTX Mounting：20*20 Φ2mm/ 25.5*25.5 Φ1.6mm/ 30.5*30.5 Φ3mm
-
Motor Mounting：16x16mm/19x19mm Φ3mm
-
Weight: 383g
Packing List
-
1 x CX10 ECO Frame
-
1 x Screw Bag
-
1 x TPU Set
-
1 x Battery anti-slip mat
-
2 x Battery straps
-
4 x AMASS MR30 Plugs
NOTE: The vertical antenna mount will be in the box when shipped and needs to be installed by the customer.
