Overview
The MAD 5X08 Drone Arm Set is a ready-to-use, high-performance propulsion system designed for industrial multi-rotor applications, including long-range inspection, mapping, and surveying drones. This lightweight yet powerful propulsion system supports 1.1-1.3kg payload per rotor, with a maximum thrust of 4kg per rotor, making it ideal for quadcopters, hexacopters, and multi-rotor UAVs. The total weight of this propulsion combo is only 288g, ensuring optimal efficiency and endurance.
Key Features
- High Thrust Performance: Capable of delivering up to 4kg of thrust per rotor, allowing for greater payload capacity.
- Lightweight & Modular Design: The entire propulsion combo weighs just 288g, reducing the overall drone weight and enhancing flight time.
- Industry-Grade 5008 Brushless Motors: Featuring KV240, KV300, and KV340 options for various flight applications.
- Advanced ESC Integration: 50A HV ESC with built-in LED indicator for precise throttle response and efficient power management.
- Efficient Carbon Composite Propellers: Equipped with HAVOC 22x7" or 18x5.7" folding propellers, optimized for reduced noise and vibration.
- Durable & Water-resistant: The propulsion system is designed to withstand dust and water, making it reliable for agricultural and industrial UAVs.
Technical Specifications
Basic Parameters
| Parameter | KV240 | KV300 | KV340 |
|---|---|---|---|
| Max Thrust (per rotor) | 4037g @24V | 3512g @24V | 3994g @24V |
| Recommended Take-off Weight | 1200g/rotor | 1150g/rotor | 1300g/rotor |
| Recommend Voltage | 6S Lipo | 6S Lipo | 6S Lipo |
| Operating Temperature | -10°C ~ 60°C | -10°C ~ 60°C | -10°C ~ 60°C |
| Unit Combo Weight | 340g (w/ HAVOC 22x7" prop) | 322g (w/ HAVOC 18x5.7" prop) | 322g (w/ HAVOC 18x5.7" prop) |
| Extension Wire Length | 700mm / 950mm (Input/Signal Wires) | 700mm / 950mm | 700mm / 950mm |
| Compatible Carbon Tube | 25/22mm | 25/22mm | 25/22mm |
Propeller
| Parameter | KV240 | KV300 | KV340 |
|---|---|---|---|
| Size | HAVOC 22x7" (558.8x177.8mm) | HAVOC 18x5.7" (457.2x144.78mm) | HAVOC 18x5.7" (457.2x144.78mm) |
| Unit Weight | 65g/pc | 47g/pc | 47g/pc |
Motor
| Parameter | KV240 | KV300 | KV340 |
|---|---|---|---|
| Stator Size | 50x8mm | 50x8mm | 50x8mm |
| Unit Weight | 142g | 143g | 143g |
ESC
| Parameter | KV240 | KV300 | KV340 |
|---|---|---|---|
| Max Input Voltage | 26V | 26V | 26V |
| Max Input Current | 50A | 50A | 50A |
| Max Peak Current | 70A | 70A | 70A |
| Max Throttle Signal Frequency | 621Hz | 621Hz | 621Hz |
| Recommend Voltage | 4~6S | 4~6S | 4~6S |
Application Scenarios
- Industrial multi-rotor UAVs
- Long-range drone inspection
- Agricultural drone operations
- Aerial mapping and surveying
- Search and rescue UAVs
Why Choose MAD 5X08 Drone Arm Set?
This propulsion system is engineered for long endurance, efficiency, and performance, making it ideal for professional-grade UAVs. Whether you're operating in aerial mapping, surveying, or industrial inspections, the MAD 5X08 Drone Arm Set provides powerful, lightweight, and highly efficient propulsion.
Details
MAD 5X08 propulsion arm set ensures maximum drone performance. Built for industrial applications, it provides a payload capacity of 1.1-1.3kg per rotor with a maximum thrust of 4kg. Weighs only 288g. Compatible with 25mm drone arm tube, offering one plug installation for convenience.
High Efficient Brushless Motor: Lightweight, 5008 motor with arc magnets, good electromagnetic design, endurance flight, water & dust proof. Propeller: Carbon composite, lightweight, solid, upward wingtip design reduces airflow interference. Integrated 50A HV ESC: Intelligent, reliable, built-in LED indicator, special core program for multi-rotor controllers.
Convenient and efficient quadcopter with MAD 5X08 propulsion combo arm set. Unit weight: 340g, flight time: 60 minutes, protection level: IP35. Product drawing includes dimensions like 238.44mm height, 463.33mm length, and various other measurements for assembly.
Specifications for 5X-5008, KV240, KV300, and KV340 propulsion combos are detailed. Includes max thrust, recommended takeoff weight, voltage, operating temperature, unit combo weight, extension wire length, compatible carbon tube size, motor stats, ESC parameters, and efficiency data for various throttle percentages.
The document details a propulsion combo's performance metrics, including voltage, current, power, torque, RPM, thrust, and efficiency at various throttle levels. It advises using the powertrain within recommended parameters for optimal performance and safety. Troubleshooting tips address issues like motor startup failure and abnormal indicator lights.
Indicator lights and audible alerts for motor controller troubleshooting. Faults during self-check include beeping sounds, flashing lights, and silent motors due to signal loss or voltage issues. Solutions involve checking connections, adjusting throttle values, and inspecting hardware. Operational faults like stalled motors require power cycling or checking for short circuits.
