Overview
The MAD 6S 10Ah Solid State Li-ion Drone Battery is a high-performance energy solution designed to power UAVs with reliability and efficiency. With a nominal voltage of 22.2V and a capacity of 10,000mAh (222Wh), it offers outstanding performance for drone applications that require both high energy density and safety. This battery is equipped with cutting-edge safety features, advanced materials, and robust protection systems to ensure prolonged flight times and enhanced safety in challenging environments.
Specifications
| Parameter | Value |
|---|---|
| Battery Model | 6s 10Ah |
| Battery Dimensions (mm) | 152 x 60 x 45 |
| Battery Weight (g) | 841 g |
| Cell Energy Density (Wh/kg) | 290 Wh/kg |
| Battery Voltage Range (V) | 25.8V - 16.2V |
| Nominal Voltage (V) | 22.2V |
| Battery Energy (Wh) | 222.0 Wh |
| Energy Density (Wh/kg) | 275 Wh/kg |
| Continuous Discharge Current (A) | 50A |
| Max. Discharge Current (A) | 100A |
| Max. Charge Current (A) | 10A |
| Cycle Life | 600 (1C) |
| Operating Temperature | -40°C to 55°C |
| Main Cable Model | 14 AWG |
| Main Plug Model | XT60H-F |
| Main Cable Length | 12 cm |
| Balance Cable Model | 22 AWG |
| Balance Plug Model | XH2.54-7P |
| Balance Cable Length | 8 cm |
Features
-
Material Innovation: The battery is designed with ionic conductor additives and lithium source additives that improve ionic conductivity and enhance the energy performance of the cell. It also incorporates a self-developed double lithium salt electrolyte formula to ensure optimal performance at both high and low temperatures.
-
Design Optimization: This battery features material ratio adjustments and an optimal density structure that enhances its energy density and ensures the safety and longevity of the cell. Custom auxiliary materials, such as earpieces and aluminum-plastic film, further enhance the energy density to meet specific customer needs.
-
Safety Improvements: The MAD 6S 10Ah battery integrates several key safety features, including:
- Flame Retardant Coatings: The diaphragm surface is coated with a flame retardant additive to enhance cell safety.
- Electrolyte Flame Retardant: The electrolyte contains additives to reduce the risk of spontaneous combustion.
- Semi-Solid System: This system ensures the overall safety of the battery under high-demand conditions.
-
Increased Protection: The battery includes lateral reinforcement using 0.5mm thick FR4 fiberglass panels, improving protection by 87% against impacts. Additionally, 2mm thick EVA shock-absorbing foam is placed at the bottom of the battery pack, cushioning it from sudden impacts during rapid UAV acceleration.
-
Appearance Optimization: The battery adopts a square and flat hard pack design, with accurate size control, ensuring the external appearance is neat and reliable.
-
Fixed Cable Routing: The battery features fixed-position cable routing at the top, ensuring clean and organized connections for smooth operation.
Precautions
- Battery Storage: Keep the battery away from flammable materials and avoid disassembling it. If the battery is damaged, dispose of it properly and do not reuse it.
- Charging: Do not exceed a charge current of 2C, and always use a qualified smart charger. It is essential that someone is present during the charging process.
- Overcharging and Safety: Do not connect the positive and negative electrodes incorrectly, as this could cause a short circuit or explosion.
Details
Drone battery, 6S 10Ah, powers flight. Semi-solid battery with 22.2V and 222Wh capacity. Continuous discharge rate of 5C, max discharge rate of 10C, and max charge current of 10A. Features include energy density, cell voltage range, and battery cycle life.
Product specifications include a 6s10Ah battery, dimensions 152*60*45mm, weight 841g, energy density 290Wh/kg, voltage range 25.8V-16.2V, nominal voltage 22.2V, and energy 222.0Wh. Continuous discharge current is 50A, max discharge 100A, charge 10A, cycle life 600 (1C), operating temperature -40°C to 55°C.
CELL ADVANTAGE, MATERIAL DESIGN SAFETY. Material innovation includes adding ionic conductor additives for improved conductivity, lithium source additives for material effect, and using a double lithium salt electrolyte formula for enhanced electrochemical properties under various conditions.
Design optimization includes material ratio adjustment, optimal density, and custom auxiliary materials. Safety improvements involve surface flame retardant coating, electrolyte flame retardant additives, and a semi-solid system. These enhancements aim to boost battery safety, life, and energy density while meeting customer needs.
Increased protection with comprehensive lateral reinforcement. Four 0.5mm thick FR4 fiberglass panels enhance battery pack armor, boosting protection by 87%. Bottom strengthening uses 2mm EVA foam to cushion impact during rapid UAV acceleration.
Appearance optimization includes square leveling and a strengthened pack. The battery is hard, flat, and accurately sized. Cables are fixed for precise control and smooth appearance. Specifications: 6S, 10000mAh, 22.2V, 222Wh. Semi-solid battery by MAD Components.
