MAD AMPX 80A (5-14S) ESC - Regulator Brushless Motor Controller For The Multirotor Drone Aircraft Heaxcopter Quadcopter Octocopter

Overview: MAD AMPX 80A (5-14S) ESC

MAD AMPX 80A (5-14S) ESC is a high-performance brushless motor controller specifically designed for multirotor drones, including quadcopters, hexacopters, and octocopters. It features quick response times, excellent compatibility and stability, and advanced technologies to enhance flight performance and safety.

Key Features:

• Quick Response: Achieves full speed from motor start in just 0.25 seconds.
• Good Compatibility and Stability: Special control algorithm for disc motors ensures seamless performance.
• Synchronous Freewheeling Technology: Provides better throttle linearity, driving efficiency, and automatic energy recovery when decelerating the motor.
• Output Interfaces: Equipped with RPM and error signal output interfaces.
• IP67 Waterproof Rating: Includes sealing, fireproof, and waterproof processes, packaged with an anti-corrosion shell.
• Convenient Installation: Features installation screw holes that do not require consideration of the ESC's front and back sides.

Protection Functions:

• Over Current Protection: Shuts off power output if the current exceeds 120A for more than 3 seconds and resumes normal operation after throttle is set to zero.
• Short Circuit Protection: Shuts off power if the instant current exceeds 240A, resumes operation after troubleshooting and powering on again.
• Stalling Protection: Triggers protection if motor stalls, resumes after setting throttle to zero and powering on again.
• Voltage Protection: Alarms and prevents motor start-up if voltage is less than 16V or more than 64V, but does not affect flying operation.
• Temperature Protection: Outputs an error signal if temperature exceeds 110°C, shuts off at 140°C, and resumes after cooling down.
• Throttle Loss Protection: Shuts off if throttle signal is lost for over 0.3 seconds, resumes after signal recovery.
• Start Protection: Shuts off if the motor does not start within 10 seconds of adding throttle, resumes after throttle is set to zero.

Application Scenarios:

The MAD AMPX 80A (5-14S) ESC is ideal for various drone applications, particularly those requiring high thrust and reliability in multirotor drones used for professional aerial photography, logistics, and industrial inspections. Its advanced protection functions and superior performance ensure safe and stable operation in challenging environments.

MAD AMPX 80A (5-14S) ESC SPECIFICATIONS

Brand Name: MAD COMPONENTS

Is Electric: No battery

Origin: Mainland China

Material: PCB

Recommend Age: 14+y

RC Parts & Accs: Speed Controllers

Size: 80A

For Vehicle Type: Helicopters

Use: Vehicles & Remote Control Toys

Certification: CE

Certification: RoHS

Upgrade Parts/Accessories: ESC

Remote Control Peripherals/Devices: ESC

Tool Supplies: Assembly Category

Quantity: 1 pcs

Model Number: MAD AMPX 80A HV-5-14S

Four-wheel Drive Attributes: ESC

ESC Parameter

Additional Cables:

• A: Power: 780mm, Motor: 150mm, Signal: 980mm, Weight: 196g
• B: Power: 330mm, Motor: 780mm, Signal: 380mm, Weight: 196g
