Motor Data
|
| Motor Model |
MAD M8C10 EEE V2.0 |
Number of pole pairs |
21 |
| Stator |
Anticorrosive |
Varnished wire Degree |
180°C |
| Motor Size |
D:87.1 × 28.7 mm |
Motor Balance |
150°C |
| Degree of Protection |
Rain protection |
Cable Length |
80 mm 16# Awg(Black) silicone |
| Centrifugal Heat Dissipation |
Independent |
Rotor Balance |
≤5 mg |
| Propeller Mounting Holes |
D:20 M3×4, D:23 M4×4 |
Motor Balance |
≤10 mg |
| Shaft Diameter |
IN: 15 mm |
Motor Mounting Holes |
D:36 M4×4, D:48 M3×4 |
| Bearing |
6802ZZ*2 |
Disruptive test |
500 V |
| Motor Data |
|
|
| Motor Model |
MAD M8C10 EEE V1.0 |
Number of pole pairs |
| Stator |
TAIWAN / Anticorrosive |
Varnished wire Degree |
| Motor Size |
D:87.1 × 28.7 mm |
Magnet Degree |
| Degree of Protection |
Rain protection |
Cable Length |
| Centrifugal Heat Dissipation |
Independent |
Rotor Balance |
| Propeller Mounting Holes |
D:20 M3×4, D:23 M4×4 |
Motor Balance |
| Shaft Diameter |
IN: 15 mm |
Motor Mounting Holes |
| Bearing |
EZO 6802ZZ*2 |
Disruptive test |
| Additional Accessories |
Propeller Plate *1, Locating Pin 1, M410mm 4 (Motor Screws), M314mm *4 (Propeller Screws), 3.5mm Bullet Connector *3, Heat Shrinkable Tube 3, Sticker2 |
|
| Specifications |
|
| RPM/V |
90 KV |
| Nominal Voltage |
12S lipo battery |
| No Load Current |
0.82A / 30V |
| Internal resistance |
122 mΩ |
| Motor Weight |
298 g |
| Product Boxed Weight |
548g (150 x 150 x 65 mm) |
| Maximum Current |
38.8 A |
| Maximum Power |
1863W |
| Maximum thrust |
9.8 kg |
| Maximum Torque |
3.8 Nm |
| Recommended ESC |
MAD AMPX 40A (5-14S) HV |
| Recommended Propellers |
32X12, 32x9.6 |
| UAV take-off weight |
12S-32"/16kg--Quadcopter |
|
24kg--Hexacopter 32kg--Octocopter |
| Single rotor take-off weight |
3kg ~ 4.5kg |
| Nominal Voltage |
12S lipo battery |
| No Load Current |
0.93A / 30V |
| Internal resistance |
110 mΩ |
| Product Boxed Weight |
551g (150 x 150 x 65 mm) |
| Recommended ESC |
MAD AMPX 60A (5-14S) HV |
| Recommended Propellers |
28x12, 29x9.6, 30x10.0, 32x9.6 |
| UAV take-off weight |
12S-30"/16kg--Quadcopter |
|
24kg--Hexacopter 32kg--Octocopter |
| Single rotor take-off weight |
4kg ~ 5.5kg |
Introducing the MAD M8C10 EEE Drone Motor, designed for enthusiasts and professionals alike! This motor offers an impressive KV100/KV90 rating, making it suitable for long-range drone applications. With a maximum thrust of up to 10.5kg per rotor, this motor is capable of handling a recommended maximum weight of 3.00-4.50 kgf. Note that actual performance may vary depending on factors such as battery level, propeller type, hover thrust, air pressure, and other conditions.
