MAD V62 PRO VTOL Drone Motor - 210KV 280KV Fixed Wing Quadcopter Motor Brushless Airplane Motor For Drone

MAD V62 PRO VTOL Drone Motor - 210KV 280KV Fixed Wing Quadcopter Motor Brushless Airplane Motor For Drone

MAD

$189.00 USD
$229.30 USD $189.00 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

24 orders in last 90 days

Color
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

MAD V62 PRO VTOL Drone Motor SPECIFICATIONS

Motor Data

Motor Model MAD V62 PRO V1.0 Number of Pole Pairs 14
Stator Japan / Anticorrosive Varnished Wire Degree 180°C
Motor Size D:72 x 37.5mm Magnet Degree 150°C
Degree of Protection Rain Protection Cable Length 80 mm (extended Enameled wires)
Centrifugal Heat Dissipation Independent Rotor Balance ≤5 mg
Propeller Mounting Holes D:12 M3x4, D:18 M3x4, D:22 M3x4 Motor Balance ≤10 mg
Shaft Diameter IN: 12 mm Motor Mounting Holes D:25 M3x4, D:30 M3x4
Bearing EZ0 6801ZZ*2 Disruptive Test 500 V
Additional Accessories M6 Propeller Plate 1, 3.5mm Bullet Connector3, Heat Shrinkable Tube3, M310mm 4 Motor Screws, M312mm 2, M318mm 2, Propeller Screws, Sticker1

Specifications

RPM/V 210KV Nominal Voltage 12S lipo battery
No Load Current 1.8A / 20V Internal Resistance 47mΩ
Motor Weight 323 g Product Boxed Weight 453g (110 x 110 x 55 mm)
Maximum Current 59.3 A Maximum Power 2846W
Maximum Thrust 11.6 kg Maximum Torque 3.13Nm
Recommended ESC MAD AMPX 80A (5-14S) Recommended Propellers 22.1x7.4
UAV Take-off Weight 125-22’’ / 20kg--Quadcopter, 30kg--Hexacopter, 40kg--Octocopter Single Rotor Take-off Weight 3.5kg ~ 6.0kg



MAD V62 PRO VTOL Drone Motor Description

MAD V62 PRO VTOL Drone Motor, Professional-grade VTOL drone motor for fixed-wing quadcopters with vertical takeoff and landing capabilities.

MAD V62 VTOL drone motor designed to carry payloads of 4-5kg per rotor, with 18-22″ carbon propeller. Max thrust is up to 11.5kg per rotor, unit motor only weighs 270g.

Built for 15-20kg MTOW professional industrial VTOL fixed-wing UAS, with large pitch VOTL CF propellers, achieving large load, high efficiency and superb reliability, providing reliable power support for various endurance flight of professional aerial photography and industry applications, i.e.: surveying, mapping exploration, security inspection, etc.

Motor Test Benchmarks

MAD V62 PRO VTOL Drone Motor, High-performance drone motor with 210KV and 280KV options, suitable for fixed-wing aircraft and quadcopters.MAD V62 PRO VTOL Drone Motor, Summary of motor test benchmarks and related information.MAD V62 PRO VTOL Drone Motor - 210KV 280KV Fixed Wing Quadcopter Motor Brushless Airplane Motor For Drone

Product Packaging


Company Profile

MAD V62 PRO VTOL Drone Motor, Introducing MAD, a reliable brushless motor designer and manufacturer for multirotor aerial vehicles and various industries.

FAQ

MAD V62 PRO VTOL Drone Motor, High-performance brushless motor for VTOL drones, fixed-wing aircraft, and quadcopters.

Certifications

MAD V62 PRO VTOL Drone Motor, High-performance drone motor with 210KV and 280KV options for fixed wing, quadcopter, or airplane use.
