MAD X7215 VTOL Airplane Drone Motor - 220KV Brushless Motor Suitable for 120E-170E Aircraft,Corresponding to Gasoline Engine About 30-40CC

MAD X7215 VTOL Airplane Drone Motor - 220KV Brushless Motor Suitable for 120E-170E Aircraft,Corresponding to Gasoline Engine About 30-40CC

MAD

$250.42 USD
$300.50 USD $250.42 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.

15 orders in last 90 days

Color
  • PayPal
  • Visa
  • Mastercard
  • American Express

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

MAD X7215 VTOL Airplane Drone Motor Overview

MAD X7215 is Suitable for 120E-170E aircraft, equivalent to petrol engine of about 30-40CC, these are very high efficiency VTOL engines. Various mounting options suitable for aircraft and multicopters. Optimised for best performance. Max thrust 14.8kg, more powerful and efficient than the same thrust motors in the market.Waterproof and dustproof. IP35 protection class.



MAD X7215 Drone Motor Specifications

Motor Data
Motor Model MAD X7215 IPE V1.0 Number of pole pairs 11
Stator Anticorrosive Varnished wire Degree 220°C
Motor Size D:81.1 × 57.5 mm Motor Balance 180°C
Degree of Protection IP35 Cable Length 150mm  (extended Enameled wires）
Centrifugal Heat Dissipation YES Rotor Balance ≤5 mg
Propeller Mounting Holes D:20 M3×4 / M8 Nut Motor Balance ≤10 mg
Shaft Diameter IN: 10 mm Motor Mounting Holes D:36 M4×4, D:90 M4×4
Bearing 6900ZZ *3 Disruptive test 500 V



MAD X7215 220KV:

Specifications Details Specifications Details
RPM/V 220 KV Nominal Voltage 10-12S lipo battery
No Load Current 2.0A/20V Internal Resistance 29.9mΩ
Motor Weight 535 g Product Boxed Weight 1261 g
Maximum Current 108A Maximum Power 5094W
Maximum Thrust 14.8 kg Maximum Torque 4.5 Nm
Recommended ESC MAD AMPX 120A (5-14S) Recommended Propellers 19x10, 20x10, 21x10
UAV Take-off Weight 12S-21" 20kg--Quadcopter Single Rotor Take-off Weight 4kg ~ 5kg
30kg--Hexacopter
40kg--Octocopter



MAD X7215 VTOL Airplane Drone Motor, Brushless motor suitable for 120E-170E aircraft, equivalent to 30-40cc gasoline engine.MAD X7215 VTOL Airplane Drone Motor, High-performance motor for VTOL airplanes, equivalent to a 30-40cc gasoline engine.MAD X7215 VTOL Airplane Drone Motor, High-performance drone motor for VTOL aircraft, suitable for 120-170cc models.MAD X7215 VTOL Airplane Drone Motor, MAD X7215: High-efficiency VTOL drone motor suitable for 120E-170E aircraft, similar to 30-40CC petrol engine.
