Radiolink RC8X 2.4G 8 Channels Radio Transmitter SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 12+y,14+y

Quantity: 1 pcs

Plastic Type: ABS

Origin: Mainland China

Model Number: RC8X

Material: Plastic

For Vehicle Type: Cars

Brand Name: RadioLink

RadioLink Hunc 8CH RC8X Silent King 4.3 Inches Full Color IPS Touch Screen 16 Models Subsidiary ID Storage Eutl

RC8X+R8FG+Battery Multilingual version R8FG DeoC C(FC Mohb Wettncrinz @##x #m+y p Y L k H 7.4V 3500mah Pranfais Hundred percend Radiouint?

On the basis of latest RC6GS V3 7 Channels radio, RC8X has the following new upgrades:

• 8 Channels

• 4.3 Inches Full Color LCD Touching Screen

• Support voice customization on all functions

• Rich Audio and Video Interfaces

• One Screen Dual Use

• 200 Groups Models Storage

• 8 Groups Programmable Mix Control

• 16 Groups ID seed

• Compatible all previous receivers R7FG, R6FG, R6F, R8EF, R8FM, R8F, R4FGM, R4F

Package List:

• RC8X radio x1

• R8FG V2.1 receiver x1

• XT60 telemetry cable x1

• Neck lanyard x1

• 32GB SD card x1

• USB cable(type-c port) x1

• Throttle trigger replacement x1

• Screwdriver x1

• User manual x1

RC8X Main Features:

• Innovative Software Technology: RC8X is for the first time runs a lightweight RTOS system on the ARM A-series chip originally running Linux. High-end configuration with ARM9 processor, 720MHz main frequency, 32M RAM and support multiple audio and video interface.

• Full Color LCD Touch Screen : 4.3 Inches 800*480 dot matrix capacitive touching screen with ultra-narrow frame and fast scroll without lag. Scary faster screen responsiveness in switching function pages, provide you mobile phone-level screen refresh experience. Besides, the screen can be used for parameter setup and FPV display at the same time when an external 5.8G receiver module is connected, easily realize dual use on one screen.

• Personalized Custom Functions: Support custom voice broadcast content, voice broadcast form, setting menu, font, the color of background and font, desktop, system theme, function button, etc; you can achieve a totally unique 8 channels transmitter without one code to modify.

• 8 Channels for Multiple Types of Models: With steering curve, throttle curve, brake curve, etc, RC8X is an ideal partner for all types RC cars and boats in the market,including single-engine and twin-engine models such as Crawlers, Tanks, Trucks, Caterpillars, Basher, Drifting,Bait Boat, etc. Pseudo random algorithm FHSS communication technology makes the control distance up to 600 meters on the ground.

• Multiple Programmable Mix Control: Support 9 groups mix control including 4WS, 4WD, tank mixing, tilt mixing, CPS mixing etc. It has 8 groups programmable mix control and any 2 channels can be easily set. You could realize every precise driving operation under different complex terrains.

• 200 Models Storage & 16 ID Seed: RC8X is capable of an arbitrary ID designation among a maximum of 16 binding receivers and can storage a maximum of 200 groups models parameters saved.A model memory with different setups can be created by using the model copy function.

• Ergonomically Designed for Hours of Fun: The steering wheel support left and right installation to meet different usage habits. Rational throttle trigger length and tension, make easy and accurate for throttle adjustment.User-friendly design for each operation and handling.

RC8X Specifications:

• Model Type: RC8X

• Channels: 8 channels

• Screen: 4.3 inches, 800*480 dot matrix, full-color, capacitive LCD touch screen

• Working Voltage:7~15V DC (8 pieces of AAA batteries or a 2S-4S LiPo battery or a 6S Ni-MH battery)

• Working Current: 290mA±10mA@8.4V(the LCD screen light on); 200mA±10mA@8.4V(the LCD screen light off)

• Model Storage: 200 models memory

• Control Range: 600 meters on ground

• Program Mix: 9 groups program mixes

• ID Seed: 16 groups

• Voice Broadcast: Support, and all the operating can set alarm with voice broadcast, buzzer, or vibration

• Menu Customized: Setting Menu, font, desktop, system theme, etc

• Low Voltage Alarm: Low transmitter voltage, low receiver voltage, low model battery voltage or low RSSI alarm can be customized

• CRSF Protocol : Support TBS Crossfire

• FPV Head Track Function: Support

• Training Function:Support

• Simulator: Support

• Headphone: Support, 3.5 mm Jack

• Extended Memory: Up to 64GB

• Language: Chinese, English and other

• Upgrade: USB online upgrade

• Transmission Power: <20dBm

• Channel Resolution: 4096 with regular jitter of 0.5us

• Spread Spectrum Mode: FHSS, 67 channels pseudo random frequency hopping

• Modulation Mode: GFSK

• Frequencies Band: 2.4GHz ISM band (2400MHz~2483.5MHz)

• Applicable Model: RC Car(Including Crawlers/Tanks/Caterpillars)/Boat/Robot

• Compatible Receiver: R8FG(Std), R7FG, R6FG, R6F, R8EF, R8FM, R8F, R4FGM, R4F

R8FG V2.1 Specifications:

• Channel: 8 channels

• Operating Voltage:3-12V

• Operating Current: 30mA

• Signals: PWM/ SBUS&PWM/ PPM&PWM

• Telemetry: Real-time built-in telemetry of model battery voltage(up 33.6V, 8S Lipo), RSSI, and receiver voltage

• Gyro: Receiver with gyro integrated, customizable gyro sensitivity

• Water Splash Proof: Yes, the waterproof grade is IPX4

• Control Distance: 600 meters

• Weight: 10.5g(0.37oz)

RC8X RadioLink Intelligent remote control Fon 8CH d percent FECHANNEL CONTROLLER RCEX .

@#+x #e+> English A+# espaiiol Deutsch Joiped Francais Multilingual version Packaging drawing Hundred pexc

Image transmission frequency: 5.8 GHz; Channel: CH-I, Channel 2; Date: September 21st; Receiver type: AV Receiver Camera; Power input: 3-5.2V; Three power options: 25mW, 100mW, and 20Om.

XT6O-plug RadioLink R8FG v2.1 Bluelp SBUS+PWM 8.0-1zvidc Matctotoo 0 + Telemetry C€ Fe RoHS Made in China com Hundred percend urple .

The RC8X screen has two modes by default. The upper part is dedicated to displaying parameters in a simple and convenient layout, while the lower portion serves as a Full-View Pilot (FPV) screen, allowing for seamless control of up to 200 models, including CH7 and CH8.

Menu settings: default steering trim, default throttle trim; DLI/PS3 code switch; VR push switch; knob switch; power switch. Quick access to home page. DT3: default dual rate; DT4: default brake 1 rate (ATL#). SPS: steering wheel push switch. Push switches SP1, SP2, and SP4; 100% PS.

The product features a DSC port for simulator connectivity, an IFPV head track, a 100% compatible USB port for data transfer, an earphone jack, five PSS push switches, two PS2 push switches, and 0.1A current rating.

RC8X 8 Channels with Full Color Touch Screen LCD More than Expectations 4.3 Inches Full Color touch screen LCD User-defined Voice Broadcast Pack FPV One Screen, Dual Use .

UBTECH, MUYUAN Food, and OceanAlpha are among the main radio transmitters used in various fields, including agriculture, industry, and security.

Breaking with traditional MCU (Microcontroller Unit) architectures, Radiolink's RC8X remote control innovatively employs an application-level CPU (Cortex-A) design that enables support for Linux-based operating systems, such as Android.

The product features an 4.3-inch full-color backlit LCD touch screen with an ultra-narrow frame, providing a smooth scrolling experience without any lag or delay, similar to that found on high-end mobile devices.

This product features rich audio and video interfaces, including a simulator function, memory expansion port (up to 64GB), and additional ports such as Type-C, FPV head tracking, and TBS Crossfire functionality for upgrade. It also has a 3.5mm headphone jack.

With the Radiolink RC8X, you can configure the DSC port to function as a simulator. Additionally, you can engage in exciting remote control showdowns with friends from the comfort of your own home, even when isolated.

Featuring various switch styles, this radio transmitter offers easy FPV display holder design, which allows for lefty-friendly functionality - the left and right recognition can be reversed. Additionally, the thumb lever enables safe one-handed steering.

Enjoy exceptional performance from the RC8X, even under extreme conditions such as off-road driving, bashing, or boating. Its impressive range extends up to 600 meters.

To activate or deactivate the gyroscope function, press the binding button three times within a two-second window. Channels 1-6 transmit PWM signals, while Channel 7 transmits PPM signals and Channel 8 transmits SBUS signals.

RadioLink RC8X V2.0: A 2.4GHz radio transmitter featuring eight channels, a 4.3-inch full-color LCD touch screen, and storage for up to 200 models. It supports multiple protocols including S.Bus, PPM, and PWM. The receiver dimensions are 35mm x 24mm x 13.5mm (1.38

R8FG has a built-in gyroscope, which can output not only PWM signals but also PPM and SBUS signals . there are four working modes including ordinary PWM mode, SBUS mode, and Gyro SBUSmode . port is only for 2S-8S battery voltage telemetry: port cannot be used to power the receiver.

For optimal performance, it's recommended to keep antennas as straight as possible to maintain the effective control range. Large models may contain metal components that can affect signal emission, so consider using foam material to reduce vibration when installing the receiver.

This transmitter is compatible with the RadioLink R8FG 2.4GHz 8-channel receiver, which features an integrated gyroscope for precise control in professional car drifting applications and supports high-voltage servos.

When purchasing an RC8X transmitter, you'll need to bind it to the receiver before use. To do this, locate the small black 'ID SET' button on the side of the receiver and press it for more than one second, then release. The LED light will flash rapidly to indicate that the binding process is underway.

RC8X is an ideal partner for various RC models, including short-course trucks, crawlers, drifting cars, gasoline-powered cars, and mini vehicles.

This customizable 8-channel transmitter allows for unique modification without requiring any code changes, enabling users to create a tailored solution that suits their specific needs.

Custom theme settings include Mii Voice node calibration, with a normal volume range from 0 to +6. The Hodel model has a maximum value of 7.4V in the system mode.

Customizable Voice Broadcast: Instead of using fixed voice broadcasts, users can opt for conditional, customizable voice broadcasts that allow for more personalized and meaningful announcements.

Total Model Count: 200 Models Storage for RC Car. Three key tone settings: Dit-Dit-Dash (DIB) Online.

All eight channels are customizable, allowing you to assign specific functions to each channel as needed. You can also define the control switches for each channel to suit your personal preferences.

The coding switch can be configured as a customizable shortcut button, allowing you to toggle between functions at your discretion.

enm Iem Proviou I/11 Provviou 211 Fron Diringl 60 FTor Dixinas FToR Diringb 60 Ieencennn Brako pxptbrk Keai doley (brak Glcinaz Glcines 405 Iront nolnt oltdl Hetmlma Innm Ketmslmehetmma Hetmmlmea

Customize your voice broadcasts to suit your specific needs, including language, format, and content. Additionally, in noisy environments, you can enjoy clear audio broadcasting through headphones without disrupting others.

Model selection: RC8X 1. Basic settings: Model Hixing (803). Receiver program: Child ID mode ON. Model select: 197, 198, 199 (Program-mixed). FHSS receivers list select model 197. Mixing channels: 3, model 19g. Program-mixing: 2.

Configure multiple mix controls, such as four-wheel steering (4WS) parameters, easily on this transmitter. The 4WS mixing feature is designed specifically for crawlers, timber trucks, and other vehicles with four-wheel steering capabilities. Additionally, the brake mixing function allows for independent adjustment of the front and rear wheels on larger scale cars, including 1/5 gas-powered models.

Experience the thrill of remote-controlled car racing with Radiolink's innovative RC8X! This cutting-edge transmitter lets you take your driving experience to new heights, with features like cruise control that allows you to effortlessly set and maintain optimal throttle volumes for your RC crawler cars.

The driving parameters, including HAX CH1 and HAx, can be preset to suit individual preferences and skill levels (100% throttle and 100% control). This feature allows parents to teach their children about remote-controlled cars in an engaging way.

The Radiolink RC8X features real-time telemetry capabilities, including RSSI (Received Signal Strength Indicator) and model battery voltage monitoring. This information can be displayed in real-time by connecting the wire to the ESC (Electronic Speed Controller), battery, and Telemetry port on compatible receivers such as R8FG, RBF, or RZFG.

The RBFG receiver features an integrated gyro that provides anti-slip functionality, ensuring smooth and stable uni-directional movement. The easy setup ensures better control over dynamic stabilization, allowing for even smoother turns.

The Radiolink RC8X transmitter features a reverse polarity protection circuit, making it easy to adapt to various battery configurations with a wide operating voltage range. This allows for compatibility with either 8 AAA batteries or a 2S-4S LiPo battery. Please note that when using 18650 lithium-ion batteries, the dimensions of the battery case should be L*W*H = 92mm x 52mm x 14.5mm (3.62 inches x 2.05 inches x 0.57 inches).

RC8X is also compatible with the 4 channels mini receivers RAFGM/RAF designed for Mini RC cars . RBFG is an 8 channels receiver with gyro built-in servo supaart andt model voltage telemetry support .
