T-MOTOR MN3510 KV700  SPECIFICATIONS

Wheelbase: Upper Shell

Use: Vehicles & Remote Control Toys

Technical parameters: Value 2

Remote Control Peripherals/Devices: ESC

Recommend Age: 18+

RC Parts & Accs: Motors

Quantity: 1 pcs

Origin: Mainland China

Model Number: MN3510 KV700

Material: Metal

For Vehicle Type: Helicopters

Certification: CE,FCC

Brand Name: T-MOTOR

T-Motor Navigator Series is a high quality, smooth running, durable brushless motor built for multirotor UAV application . the custom assembly methods and components unique to Navigator series help to provide the reliability required for a dependable aerial platform.

The motor features a reliable propulsion system, ensuring dependable performance in aerial applications.

T-MOTOR's MN3XXX series features high-quality bearings, specifically EZO bearings that are originally imported to ensure consistent performance at low velocities.

T-Motor's MN3510 KV700 Outrunner Brushless Motor features a flexible mounting system with adjustable hole designs, allowing for compatibility with various propellers. The primary mounting holes have a 25mm x 25mm installation dimension, suitable for standard main props.

The package includes one (1) set of M6 prop adapters and four (4) screws (M3 x 12mm) specifically designed for installing T-Motor CF props.

Test Report Test Item MN3510 KV630 Report NO MN.00015 Specifications Internal Resistance 65mn Configuration 12NI4P Shaf Diameter 4mm Motor Dimensions 041.8*28.5mm Stator Diameter 35mm stator height 1Omm AWG 18# Cable Length 600mm Weight Including Cables 119g Weight Excluding Cables97g Noof Cells(Lipo) 34S Idle Current@1Ov Max Continuous Power 180S

MN3510 KV700: Test Report Item MN00016. Specifications: Internal Resistance: 50mohms Configuration: 12N14P Shaft Diameter: 4mm Stator Height: 10mm AWG Cable: 18# Cable Length: 60mm Weight (including cables): 118g Weight (excluding cables): 99g Number of Cells (Lipo): 34S Idle Current at 10V: 0.5A Maximum Continuous Power: 180S @ 5V Maximum Continuous Current: 18A
