RCINPOWER SmooX 2806 Plus 1350KV 1750KV Brushless Motor for 7 Inch FPV Freestyle Long Range Racing Drones

RCINPOWER SmooX 2806 Plus 1350KV 1750KV Brushless Motor for 7 Inch FPV Freestyle Long Range Racing Drones

RCINPOWER

Regular price $31.80 USD
Regular price Sale price $31.80 USD
Sale Sold out
Taxes included. Shipping calculated at checkout.
Color
View full details

1PC RCINPOWER SmooX 2806 Plus Brushless Motor 1350kv 1750kv 7 Inch Propeller Freestyle Long Range For RC FPV Racing Drone Parts

SmooX 2806 Puls new features:

1. Overall 7075 super-hard aviation aluminum material, new appearance craft, dazzling and beautiful;

2. New rotor shape, lower temperature after optimized aerodynamic structure;

3. Continuing the solid luxury materials of GTS v2 series, the stator is 2806.5, the power is more powerful and efficient;

4. Larger imported bearings than the same level are adopted, which improves durability, stability and longer motor life;

5. The winding is increased to military-standard temperature-resistant 260 ° C oxygen-free single crystal copper wire, which once again improves the stability under extreme conditions;

6. Extend the use of 2207PLUS to create the first A.I.P and B.F.P damping technology rotor design, which effectively improves the life of the motor and the feel of the flight, and reduces the flight control burden;

7. Give the concept of smooth + X (extreme sports) pertinently, and the throttle linearity is improved again, smooth! Smooth! Smooth!

8. Adjust the winding, and then increase the efficiency, while saving power, the dynamic response is still rapid and powerful;

9. Repeated tests confirmed that for 7-inch paddles, 1750KV is suitable for heavy load and high maneuverability Freestyl flight, and 1350KV is suitable for long-endurance and high-efficiency voyage FPV!

Key Features


  • Size: 2806.5

  • Kv: 1350

  • Weight: 47g

  • Color: Chrome

  • Mounting holes: 19mm M3

  • Magnets: N52H ARC

  • Shaft: Super hard alloy steel shaft

  • Bearings: d4*D13*H5 624zz Japan ISC

  • Winding: 260℃ Class Single oxygen-free copper

  • Shell Material: 7075-T6

  • Cables: 28AWG 9cm


Package Includes


  • 1x Engine

  • 1x Set of screws

SmooX 2806 Motor: Professionally manufactured with purple design, silver shaft, and high-performance components.

SmooX 2806 Motor, professional manufacturer, purple design, silver shaft, high-performance component.

SmooX 2806 Motor, SmooX 2806Plus motor, 1350KV, 12N14P, 28mm stator, 6.5mm length, 47g weight, 960W power, 40A current, perfect for RC use.

SmooX 2806Plus motor, 1350KV, 12N14P. 28mm stator, 6.5mm length, 47g weight. Max 960W power, 40A current. Ideal for RC applications with efficient performance.

SmooX 2806 Motor, SmooX 2806Plus motor: 1750KV, 28mm stator, 4mm shaft, 47g weight, max 1200W/50A, >86% efficiency, with performance data for various props.

SmooX 2806Plus - 1750KV motor specs: 12N14P, 28mm stator, 6.5mm length, 4mm shaft. Weighs 47g, max 1200W power, 50A current, >86% efficiency. Includes voltage, throttle, load, pull, power, and temperature data for various props.
