RJX 30mm / 35mm Motor Mount Kit for 80A 100A ESC Motor Agricultural Drone Motor Accessory

RJX 30mm / 35mm Motor Mount Kit

The RJX motor mount kit is specifically designed for agricultural drones, offering robust support and heat dissipation for high-power motors and ESCs (Electronic Speed Controllers). This motor mount is built to accommodate 30mm and 35mm carbon fiber tubes, ensuring a stable and secure attachment. The design is optimized for use with powerful motors like the W9235 and Q9XL, and is fully compatible with Hobbywing 80A and 100A high-voltage ESCs, making it ideal for heavy-duty agricultural drone applications.

Specifications:

• Color: Black, Red
• Weight: 116.7g
• Inner Diameter (ID): 30mm / 35mm

Matching Screws:

• 35mm Motor Mount:
  • M3x45 (1 pc) + M3 Nut (1 pc) + M3x8 (4 pcs) + M3x12 (2 pcs)
• 30mm Motor Mount:
  • M3x10 (4 pcs)

Compatibility:

• Suitable for 30mm / 35mm carbon fiber tubes
• Compatible with motors including W9235 and Q9XL
• Perfect fit for Hobbywing 80A and 100A high-voltage ESCs

Key Features:

1. Optimized for High-Power Applications: The motor mount is designed to support powerful motors and ESCs, ensuring stable performance in agricultural drones.
2. Enhanced Heat Dissipation: The sides and base are equipped with abundant ventilation holes to prevent overheating, even during extended operations.
3. Wide Compatibility: Compatible with both 30mm and 35mm carbon tubes, allowing flexibility in drone frame design.
4. Sturdy and Reliable: Built with high-quality materials, the mount provides excellent durability, ensuring secure motor attachment even in demanding conditions.

Package Includes:

• 1 x Motor Mount Set

Important Note: Before purchasing, please check and ensure that the hole spacing on this motor mount is compatible with your motor for a perfect fit.

This RJX motor mount kit is an excellent choice for agricultural drones, offering the reliability and performance needed for heavy-duty tasks, while also accommodating high-power ESCs for optimal efficiency.
