The pins on connector I2C#2 are reversed as with respect to connector I2C
ALL boards HAVE the diode required for running a bluetooth module!!!
SPECIFICATIONS
supply voltage:3S battery
motor current: max. 1.5 A per motor
Comment: This is not yet fully exploited, motors with resistances of 12 Ohm , motors with 10 Ohm may be handled with care (see here andhere).
board dimensions: 50 mm x 50 mm, 45 mm bolt to bolt, holes Ø3 mm
Warm notice:
1. Recommended power supply is 12V(3s battery);
2, Camera must be fixed in the head (without any loosening);
3. Adjust the Gopro camera to the left or right,so that the camera is at Horizontal level;
4. Before camera fixed in the gimbal , please do not push " on " button to have power.
5,The gimbal camera must be use belt tight, otherwise it will have problems. And if you do this many times, it will cause damage to the flight controller.
- 1 x Aluminum gimbal installed 3 motors(assembled)
