SPECIFICATIONS
Wheelbase: Bottom Plate
Upgrade Parts/Accessories: Adapter
Tool Supplies: Battery
Technical parameters: KV1100
Size: as description
Remote Control Peripherals/Devices: Remote Controller
Recommend Age: 12+y
RC Parts & Accs: Principal Axis
Quantity: 1 pcs
Origin: Mainland China
Model Number: SIYI ZR10
Material: Composite Material
Four-wheel Drive Attributes: Assemblage
For Vehicle Type: Airplanes
Brand Name: uuustore
Technical Specifications
Overall
Model: ZR10
Video Output Port: Ethernet
Control Signal Input Port: S.Bus / PPM / UART / UDP
Power Consumption: 5 W
Dimension: 121*101*78 mm
Weight: 381 g
Waterproof Level: IP53
Angular Vibration Range: ±0.01°
Working Voltage: 11 ~ 25.2 V
Working Temperature: -10 ~ 50 ℃
Camera
Lens: 10X Optical Zoom, 3X Digital Zoom
Focal Length: 5.15±5% ~ 47.38±5% mm
Aperture: F1.8 ~ F2.5
Focus: 0.2 m to ∞
FOV: Diagonal 79.5°, Horizontal 71.5°
CMOS: 1/2.7”, 4 MP
TF Recording Resolution: 2560*1440 @ 30 fps
Video Storage Bitrate: 12 Mbps
File Storage Format: FAT32
Still Photography Mode: Single
Image Format: JPEG
Video Format: MP (Originally recorded in H.265 file, converted to MP4 file after reboot)
Metering Mode: Evaluative metering
White Balance: Auto
Supported MicroSD Cards: MicroSD Class10 (Max 32GB, will support 128GB by firmware update)
Package List:
1 x ZR10 Gimbal Camera
1OX Optical Zoom Support TF Card 3-Axis 3x Digital Zoom Pixels 2K Video Recording Gimbal Stabilizer Photography HDR High-Precision High Starlight Night F1.8 Aperture FOC Control Dynamic Range Vision Camera u@USIC
ZRIO gimbal camera supports 30x hybrid zoom . fast and accurate algorithm makes it fccus quickly and quite easy to output high- quality videos .
4OOMP 2K Recording ZRIO comes with CMOS of 400 megabits of effective pixels Video resolution Is up to 2560x1440 . Recording supports Class 10 high-speed MIcOSD present to customers videos full of elegant detalls .
ZRIO gimbal camera appliad wlth Industry-level 3-axis stabilizing technology and hilgn-precision FOC control algoritnms reduces moSt image shaking and ensure tnat the imaga is elways stable even if tha aircraft cr the venicla Is In vigorous movement, ard the camera will continuously output stabla and clear images .
starlight CMOS can precisely cepture detalls of ard shadows in dynamic scenes, getting awav of Iow Iight or backlignt . uitra-sensitive starlight camera can keep image bright evan .
ZRIO 30X hybrid zoomn camera, working with HD Image transmission cevices, can be applied in va-rious asse1 Inspection scenes such as electric towers and wind turbines arones equipped wilh encugh distance t0 finish nspection by creckirg the received zoom irages over the air efficiently and safely.
Product Diagram IP Video Output Recorder TF Card Gimbal Control Input Power Input S.Bus/PPM/UART/UDP 11-25v
