T-motor MN2212 KV780 KV920 Brushless Motor SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Recommend Age: 18+

RC Parts & Accs: Motors

Origin: Mainland China

Model Number: MN2212 KV920

Material: Metal

For Vehicle Type: Airplanes

Brand Name: T-MOTOR

the motor is high quality, smooth running durable brushless motor built for multirotor UAV application . the custom assembly methods and component unique to Navigator series help to provide the reliability required for dependable aerial platform:

With extensive testing and rigorous data analysis, we can confidently ensure that the MN2212 motor is a flawless upgrade option for 2216, 2217, and 2810 models, offering unparalleled performance and reliability.

T-Motor's MN2212 KV780/KV920 brushless motors feature oversized bearings, twice the size of similar motors in their class, which enables low-speed, smooth operation and provides a stable frame even under heavy loads.

The motors come equipped with high-quality EZO bearings, designed to enhance the lifespan of the motor. Although they are imported with original packaging, we highly recommend replacing the bearing after reaching 60 hours of flight time to ensure a safe and reliable flying experience.

Featuring a flexible mount hole design, this motor is compatible with various standard mounting patterns, including 16x19mm and 19x25mm configurations, allowing for easy installation of main propellers.

Product Specifications: MN2212-V20 KV780 Motor. Key Features: Internal Resistance - 173mΩ, Configuration - 9NIZP, Shaft Diameter - 4mm, Stator Height - 13mm, AWG 20# Cable Length - 400mm, Weight (including cables) - 65g, Weight (excluding cables) - 55g, Number of Cells (Lipo) - 24S. Performance Data: Idle Current @ 10V - 0.4A, Max Continuous Power - 180S, 200W, Max Continuous Current - 13A. Load Testing Data: Ambient Temperature [insert temperature range or note].

MN2212 V2 KV920 Report NO. MN.00007 Specifications Internal Resistance 142m0 Configuration 9N1ZP Shaf Diameter 4mm Motor Dimensions 027.5*26.Smm Stator Diameter 22mm . Stator Height 13mm AWG 20# Cable Length 400mm Weight Including Cables 65g Weight Excluding Cables 54g Noof Cells(Lipo) 24S Idle Current@1Ov 0.5A Max Continuous Power
