SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Technical parameters: Value 2

Remote Control Peripherals/Devices: ESC

Recommend Age: 14+y

RC Parts & Accs: Engines

Origin: Mainland China

Model Number: MN4110

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Airplanes

Brand Name: T-MOTOR

Remarkable cooling long endurance With reasonable airflow channel design, heat flux increases by 18% . high-performance iron core material, high slot rate and reduced

With an efficiency of up to 8g/W at 60% throttle, this motor provides fast and carefree flight with its 12N14P configuration.

Specifications Motor Size p47.4*36.7mm Imported silicon steel sheet; Stator Anti-rust treatment; 80-C high temperature-resisting coatings Configuration 12N14P Shaft Diameter IN: 6mm OUT: Bearing 6867Z/696ZZ Magnet Level N45SH Lead Cable 16AWG*1SOmm 220*C High temperature resistance: Copper Wire Level € Coil Insulation Test 50Ov/ss Centrifugal Cooling Design YES Rot

Key Specifications: * Idle Current: 0.9A (measured at 10V) * Recommended Propeller Size: P17-18

For coaxial configurations, please note that there may be a 25% thrust loss due to wing force. For single-rotor VTOL ESC applications, we recommend using a rotor-driven motor design.
