T30-Pro 30X Optical Zoom PTZ 2MP Pixels w/ HDMI Output 1080P Tracking Function Z30P1

Package Included:
- 1 x PTZ Main Unit HDMI Version
- 1 x Parameters Setting Module
- 1 x PTZ Power Cord
- 1 x S.Bus Receiver Cable
- 1 x Serial Cable
- 1 x Micro-USB Cable
- 1 x Video Output Debugging Module
- 1 x Micro-SD Memory Card 32GB

Description:
The T30-Pro is a three-axis optical zoom PTZ developed for industrial applications. It is equipped with a 30X optical zoom lens and a high-performance 1/2.8'' CMOS sensor with a maximum real-time recording resolution of 2.16 million. It has built-in high-precision sensor module and integrated servo-driven module for stabilization and stability. The image stabilization accuracy is up to 0.01°. It can be widely used in electric power inspection, security and search and rescue industries.

Features:
- Equipped with a professional 30X optical zoom camera
- Three-axis image stabilization
- Leading dedicated decoupling attitude algorithm
- Highly optimized servo motor vector control algorithm
- Control frequency up to 5000Hz
- Stabilization accuracy of ±0.01°
- All aluminum alloy structure design features light and sturdy, good heat dissipation performance
- HDMI video output interface
- Support intelligent tracking

Functions:
- Video Output: HDMI (1080P 30FPS)
- Supported Control Mode: UART (TTL), S.Bus
- Advanced Function: Intelligent Tracking

Technical Parameters:
- Sensor Size: 1/2.8'' CMOS
- Pixels: 2.16MP
- Video Resolution: 1080P@30fps
- Optical Zoom: f:4.7 ~141mm
- FOV (Horizontal): 60~2.3°
- Minimum Illumination: Colorful: 0.05Lux/F1.5; Black & White: 0.005Lux/F1.5
- Video Compression Mode: H.265/H.264/H.264H
- Memory Function: Support TF Card up to 128G
- Stabilization Accuracy: ±0.01°
- Max. Controllable Speed:
  PAN: ±200°/S
  TILT: ±200°/S
- Controllable Rotation Range:
  PAN: ±360°Continuous
  TILT: -120 to 30°
- Working Environment: -20 to 60℃
- Storage Environment: -20 to 70℃
- Humidity: ≤85% (Non-condensing)
- Working Voltage: 20 to 52V
- Average Power Consumption: 8.0W
- Dimensions: 152 x 144 x 162mm
- Weight: 675g
