Tarot TL5D001 5D3 3-Axis Self-stabilizing Gimbal Camera Mount IMU Support S-Bus/PPM/DSM for Canon EOS 5D Mark III PF Mode

Tarot TL5D001 5D3 3-Axis Self-stabilizing Gimbal Camera Mount IMU Support S-Bus/PPM/DSM for Canon EOS 5D Mark III PF Mode

Tarot

Regular price $730.68 USD
Regular price $1,022.96 USD Sale price $730.68 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

5 orders in last 90 days

Warehouse: China/USA/Europe, can delivery to all countries;

Free Shipping: 9-15 days;

Express Shipping: 5-8 days;

Return&Refund: 30 Days.

View full details

Tarot TL5D001 Gimbal SPECIFICATIONS

Wheelbase: Screws

Upgrade Parts/Accessories: Adapter

Tool Supplies: Cutting

Technical parameters: Value 2

Size: As description

Remote Control Peripherals/Devices: Remote Controller

Recommend Age: 14+y

RC Parts & Accs: AXLE

Quantity: 1 pcs

Origin: Mainland China

Model Number: Tarot TL5D001

Material: Composite Material

Four-wheel Drive Attributes: Assemblage

For Vehicle Type: Airplanes

Brand Name: uuustore

Tarot TL5D001 5D3 3-Axis Self-stabilizing Gimbal Camera Mount for Tarot X6 Hexcopter Fpv Canon EOS 5D Mark III PF Mode



Introduction:
The Tarot 5D3 3-Axis self-stabilizing gimbal is specifically designed to carry the Canon 5D Mark III and 5D Mark II camera and perfectly match with Tarot X6 Hexacopter. Its CNC processing with thin-walled structure gives you a stable footage and precise control even in the most difficult flight conditions.

The Tarot 5D3 is based on gimbal system with optimal algorithm. Built-in independent IMU module gives you precise and effortless control. Three working modes are supported, orientation locked, Non orientation locked and FPV. Built-in slip ring simplifies the cabling. The command stick controls gimbal rotation velocity.

Tarot 5D3 3-Axis self-stabilizing gimbal can be converted into handheld gimbal with quick release handle (the handle needs to be purchased additionally). Tarot 5D3 3-Axis self-stabilizing gimbal is your best choice.

Features:
- Working modes
Orientation-locked control
Non orientation-locked control
FPV mode
- Bulit-in independent IMU module
- Tarot gimbal special servos drive module
- AV output port
- Camera shutter control supported
- Wide range voltage input supported
- S-Bus/PPM/DSM receiver supported

Peripheral
- Supported Camera: CANON EOS 5D MARK III & 5D Mark II only
- Supported Lens Currently: CANON EF 17-40mm f/4L USM
- GCU Input Power: 3S~6S LiPo
- Control Requirement: At least four spare receiver channels
- Assistant Software System Requirement: Windows XP SP3; Windows 7; Windows 8 (32 or 64 bit)

Mechanical & Electrical Characteristics
- Working Current: 120mA (@25V) 180mA 3S-6S Li (11V-26V)
- Operating Temperature: -20°C ~ 50°C
- Weight: 1.51KG
- Dimensions: 215mm*240mm*246mm

Working Performance
- Controlled Angle Accuracy: ±0.02°
- Maximum Controlled Rotation Speed:
- Pan axis: ±200°/s
- Tilt axis: ±200°/s
-Roll aixs: ±200°/s
- Rotation:
- Pan axis control: ±360° continuous rotation
- Tilt axis control: -135°-+45°
- Roll axis control: ±48°

Built-in independent IMU module gives you precise and effortless control

three working modes are supported, orientation locked, Non orientation locked and FPV

TAROT pre TaROU Faud b;TorKcol 1 1

built-in slip ring simplifies the cabling

built-in slip ring simplifies the cabling

Tarot TL5D001 5D

Tarot 5D3 3-Axis self-stabilizing gimbal can be
